PET tape coating machine is suitable for kraft paper coating, sticker paper coating, adhesive paper coating, silicon paper coating, double faced paper coating, PET film coating, PVC film coating, PE tape coating, etc.
1.Application:
Suitable for the basis materials such as PET,foam tape,and PE protective film etc.
2.Feature:
(1)Straight-scraping transfer printing type gluing,laminating kinds of basis materials.
(2)Double-position air-operated unwinding and rewinding .
(3)Automatic switching,cutting cloth and connecting film.
(4)Outside heated drying case,SUS304 inside layer fabrication.
(5)Automatic tension segmentation control.
(6)Segmentation control temperature and adjustment according to the technical process.
3.Technical parameters:
Model |
HFT-500 |
HFT-1000 |
HFT-1300 |
HFT-1600 |
|||
Valid width |
500mm |
1000mm |
1300mm |
1600mm |
|||
Mechanical speed |
5-50m/min |
5-90m/min |
90m/min |
5-90m/min |
|||
Coating average degree |
±0.015mm |
||||||
Rewinding edge smooth |
±2mm |
||||||
Total mechanical speed |
20-65HP |
20-80HP |
30-80HP |
40-100HP |
|||
Oven length |
design upon the request of the customer |
||||||
Heating |
hot air |
||||||
Power supply/voltage |
380v 50HZ |
||||||
4.3-Dview of the main part
5.What can we offer?
Whole production line for making adhesive paper and tape, from coating machine,
slitting machine, cutting machine to printing machine. Turn on key base offer.
6. Why choose Hongfat?
The best choice for turn on key offer.
6.1Hongfat can really help you to set up the coating factory from zero, no matter
machine production, installing, training for operator, maintenance, raw
material supplier identify and business convoy.
6.2 He can lend you English-speaking operator.
6.3 Some machine is 3 years’ guarantee.
6.4 English-speaking engineers have the experiences of serving more
than 20 countries.
They are many company which is much bigger than Hongfat, they are
many company who can make good machine as Hongfat. Especially,
when we talk about machine, we like to say German machine is good.
While after they get your money, few of them can really be patience
to set up your business from Zero. Especially when your request seems
out of their duty,Especially the job is beyond the duty of machine seller.
If you have good experience already and just want good machines. Hongfat
is one of your choice. If you want to set up the coating factory from
Zero, Hongfat is your only choice.
7.Machine guarantee?
2 years
8.Sample produced by the machine
9.Factory view and export loading
10.Fair in overseas
