Specifications
1.11Years'experience2Brand pulverizer,shredder,sifter,separator
3Lifetime warranty
4.Lowest price
5.ISO9001SGSCertification
Tyre Wire Drawer For Waste Tire/ Tyre Recycling Machine
Advantage:
1.11Years'experiences manufacturer
2.China expert on waste rubber pulverization
3.Brand pulverizer,shredder,crusher,screener,separator,grinder
4.Lifetime warranty,lowest price
5.ISO9001,SGS certification
Summary:
Since the pollution from the growing waste tyres of vehicles, it has put the treatment of waste tyre before everybody, however, it is frequent to see the re-use of steel. When comminuting the tyre directly, its thick steel wire inside makes a biggest test to the service life and material quality of cutter.
Usage:
Removing the whole steel wire of the inner ring of radial tyre with a diameter less than or equal to 1200mm.
Structure & Principle:
Switching on the power to start the motor, making the two notches of the disc under an open state completely, then placing the tyre into the press vertically (See the figure above); afterwards, switching on the motor (two hooks will rotate upwards simultaneously) . After the whole steel wire is removed away from the tyre completely, it can then be allowed to take the steel wire out of the press.
Main Technical Data:
| Model | Power(kw) | The Max Journey | Matching Tire | Pull(Newton) | Frequency(time/min) | Weight(kg) | Overall Dimension L*W*H (m) | ||
| 900-type | 15 | 800-type | ≤1200 | 11 | 2 | 680 | 1.9*1.06*1.36 | ||
Wearing Parts Maintance:
Type |
Material |
Operation time |
Repairing method |
Instruction |
Bearing |
|
5000 |
Replace |
General part |
Drawing hook |
Alloy |
10000 |
Build up welding again, then polish or purchase |
tungsten carbide surfacing electrode |
Cross recess mould |
Cr12,HRC55~58° |
20000 |
Replace |
Purchase |
Delivery time: 25-35 days after receiving 30% deposit.
Service: Provide Installation, maintenance and technical guidance for life.
Guarantee:Quality free for One year,maintainance for lifetime
P.S:The quality guarantee is 12 months after finishing the trial run of machines which has been shipped to the buyer side. If any part (excluding easily damaging parts) is found defective in quality within warranty period, we would like to replace it for free. After warranty, spare parts can be replaced based on favorable price.
We produce rough crusher, shredder,automatic tire cutter,bead-wire drawing machine,tire splitting machine,separator,screener,conveyer and all kinds of waste tire recycling machines,and with the strong technology we can accept custom made!
