Specifications
1 Size:width 0.3 m,to 6 m, length 100 m to 2000 m2 Weight: 40gsm to 600gsm
3 Oil & water chemical stability & compatibility
Campared with staple polyester geotextile, filament polyester geotextile have below advantages,
- Larger coefficient of friction,
- higher UV-resistant property, only the surface impact by the UV radiation.
- Better puncture resistance and excellent creep resistance in same mass per unit area
- Large porosity reduce clogging
Overview
Nonwoven filament polyester geotextiles, Manufactured from Polyester fibres,they have a unique filament fibre blend and an inbuilt flexibility with the help of the needle punching technology. It Comprises variety of thicknesses, weight and forms and each has its own special function. For a long time, it is an idea choice to be used as they have unique properties that have economical benefits like less material be used, quick and easy installations.
Application
For its UV resistance, Chemical stability and compatibility of oil and water, there are at least 80 specific applications area for geotextiles that have been developed. Mainly on Separation, Drainage, Filtration, Reinforcement and Protection. In the really project, it could work well as below,
l Road Works
l Ground Stabilization
l Drainage and Filtration Systems
l Construction Works
l Waste Disposal Sites and Water Purifying Plants
Technical Date
International standard ASTM |
Unit |
A14 |
A19 |
A29 |
A44 |
mass per unit area |
g/sqm |
160 |
200 |
250 |
380 |
thickness |
mm |
1.2 |
1.6 |
2.2 |
2.8 |
Width deviation |
|
0.005 |
0.005 |
0.005 |
0.005 |
elongation at break |
|
30% |
35% |
40% |
50% |
Wide Strip Tensile Strength(MD/XMD) |
KN |
6.2/5 |
8.5/7 |
10.2/8.5 |
14.5/13.2 |
Grab Tensile Strength(MD/XMD) |
N |
535/450 |
750/670 |
1095/1020 |
1905/1720 |
CBR Burst Strength |
N |
650 |
970 |
1300 |
2000 |
Pore Size |
μm |
110 |
100 |
90 |
85 |
Coefficient of Permeability |
m/s |
34 |
34 |
34 |
34 |
Trapezoidal Tear Strength (MD/XMD) |
N |
240/220 |
305/295 |
430/385 |
700/660 |
Permittivity |
1/s |
2.4 |
2.2 |
1.8 |
1.2 |
Two layer,the outer layer is plastic film to protect wear and tear, and the inner layer is PE film to seal for water.
Strong packed, and ease for long distance transport and shipment.
