Flexible Rubber Threaded Expansion Joint
Features of EPDM Rubber Joints:
1.The form: this product consists of rubber pipe ,made of inner glue ,multi-layer frame and cord fabric and outer glue and metal woggle joint .
2.It is applicable for the connection of inlet and outlet pipes of various fan coil sets of air conditionings in the guest rooms of hotels and restaurants.
Application medium of EPDM Rubber Joints:
Air,compressed air,water,sea water,hot water,oil,acid,alkali,etc.
Purpose of EPDM Rubber Joints:
and pump valve connection fire fighting equipment, vibration large pipe cold and hot change frequent pipeline
Advantages of EPDM Rubber Joints:
high quality rubber joint recommend quotient lead to reduce vibration noise retractility, easy to use
Technical Conditions of EPDM Rubber Joints:
working pressure MPa(kgf/cm2 ) |
1.0(10) |
deflection angle |
(a1+a2 )45° |
burst pressure MPa(kgf/cm2 ) |
3.0(30) |
Vacuum KPa(mm/Hg) |
53.3(400) |
applicable temperature |
-15~115`C(for special conditions)-30~250`C |
||
applicable media |
water, sea water, hot water, air, compressed air ,oil, acid, alkali, etc. |
||
Main connecting dimension of EPDM Rubber Joints:
nominal diameter Dg |
length(mm) |
axial displacement |
horizontal displacement mm |
||
mm |
inch |
extension |
compression |
||
20 |
3/4 |
200 |
5~6 |
22 |
22 |
25 |
1 |
200 |
5~6 |
22 |
22 |
32 |
1 1/4 |
200 |
5~6 |
22 |
22 |
40 |
1 1/2 |
200 |
5~6 |
22 |
22 |
50 |
2 |
200 |
5~6 |
22 |
22 |
65 |
2 1/2 |
200 |
5~6 |
22 |
22 |
Detail photos of EPDM Rubber Joints:
Packaging Detail: First every EPDM Rubber Joints packaging is carton case,then the Wooden cases outside.
Shipping:
1.Lead time: about 25-30 days after order is confirmed.
2.If the order is urgent, we will try to give the best delivery time;
3.Our delivery time is accurate and fast, it is one of our advantages;
4.We cooperate with many famous logistic companies to ensure that we can ship your cargo to you on time.
You can choose the right means of transportation.
Promise and service from us:
- We offer good quality products in competitive price.
- We have rich experience in this industry.
- We have short delivery time .
- Shipped the goods on time.
- Meet your special requirements.
Our company is specialized in water supply and drainage equipment,pipe and parts.Through 20years production history,
it is solid in strength and good in quality.Employees are skilled and experienced.It cooperates with design institues and research institutions jointly for research and development.The design of product is unique and the structure is rational and updated.
At present,our products have over 30 types such as JGD flexible synthetic single sphere and
double sphere rubber expansion joint,thread joint, unequal diameter,DN15-DN3000 and so on.
Completed types,high quality and lower price make its products ideal for water supply and drainage,
heating pipe and building field.
Our products have been exported to many countries such as England ,France,America,Australia,Singapore and India etc.
and won a high admiration and is widely trusted at home and abroad.
So Product quality is guaranteed.
If you are interest in our company and our EPDM Rubber Joints you could visit the website or contact us:
Http:// /gyhuayuan
FAQ:
Q : Can you make the product as per client's requirement?
A: Yes, can make it with your exact requirement.
Q: What is your payment terms?
A: T/T(30% as despot,the rest 70% will be paid before delivery) , L/C at sight
Q: can i visit your factory before the oreder?
A: Yes, welcome to our factory to check the quality.
Q: Where is your nearest loading port ?
A: Shanghai, Qingdao or Tianjin ,China.
Q: How can you guarantee the quality or any warranty?
A: If any quality problems during use, all the products can be returned
or according to consumer's requests.
Q:Do you accepted small quantity order?
A: Of course we do.
Q:Can we choose different material?
A: Yes ,the material can be chose according to your requirement.
Q:And What's your shipment and delivery time?
A:By sea or air.Normally 7~14 Days for delivery ,according to your order quantity.
Q:And what's your packing?
A: carton cases inside ,export wooden cases outside
