Stainless Steel Bellows Expansion Joint(s)

Name: Stainless Steel Bellows Expansion Joint(s)
Brand: HUAYUAN
SKU: 102839715
Availability: InStock

US$ 2.56 - 132.6 MOQ: 5 Pieces

Key Specifications

Material:

Stainless Steel

Technics:

Forged

Type:

Other, Coupling, Axial Expansion Joint and flange

Gongyi Huayuan Water Supply Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Material Stainless Steel

Technics Forged

Type Other, Coupling, Axial Expansion Joint and flange

Place of Origin Henan, China

Model Number JZBW

Brand Name HUAYUAN

Connection Flange

Shape Equal

Head Code Square

Stainless Steel Bellows Expansion Joint(s)

Product Description

Features Of Stainless Steel Bellows Expansion Joint(s):

a. good flexibility.

b. Can produce axial deformation

and transverse and Angle to the displacement.

c. used for chemical industry, smelting ,water supply ,dewatering structure and so on .

main connection size

main connection sizes Of Stainless Steel Bellows Expansion Joint(s):

Nominal diameter (mm)	type			compensation length(mm)			toughness(N/mm)			Active area (cm²)	Maximum diameter (B)(mm)	The size of connection end (Φ×s)	protective casing externial size (D₁) (mm)	Total length(L)mm
				Axial X.	Horizonal Y.	angular θ./temperature	Axial K_X	horizonal K_Y	angular KQ N-m/temperature					flange	connection tube
32	QM JZ	BW1.0/32×8	J F	7			441			16		Φ38×3.5	186		280
				7	1.28	±4	441	774	2		225			164
	QM JZ	BW1.0/32×16	J F	14			220			16			186		321
				14	5.1	±8	221	97	1		225			216
40	QM JZ	BW1.0/40×8	J F	10			317			23		Φ45×3.5	224		289
				10	1.5	±4	318	696	2		244			219
	QM JZ	BW1.0/40×16	J F	19			158			23			224		334
				19	6.1	±8	158	87	1		244			219
