Specifications
Long Distance Passive UHF RFID Reader*TCP/IP ,RS232,Wiegand RFID Reader
*Long distance 3-15m
*Free SDK
*ISo18000 6C/Gen 2
Long Distance Passive UHF RFID Reader
*TCP/IP ,RS232,Wiegand RFID Reader
*Long distance 3-15m
*Free SDK
*ISo18000 6C/Gen 2
Application
*Vehicle Management
*Parking system
*Store management
*Property management
*Access control
*Card authorization
Character
Basic Parameters | |
Model |
MS-9801H Long Distance RFID Reader |
Dimensions |
440mmX440mmX50mm |
Weight |
2 Kg |
Operating Temp |
-20°C to +80°C |
Interface |
Standard: Viegand26, Viegand 34, RS485, RS232, set by software Optional: WiFi, RJ45 |
Data Input Interface |
One group Trigger Input |
Indicator |
Buzzer |
Power Supply |
DC 9V (equipped with power adaptor) |
Certificates |
FCC CE CCC |
RFID Parameters | |
Frequency Range |
Standard ISM 902 to 928MHz and ISM 865 to 868 for option, can customized other frequency |
Protocols |
ISO18000-6B, ISO18000-6C (EPC GEN2) |
Work Mode |
FHSS |
RF Power |
0 to 30dBm, set by software |
Antenna |
Build-in 12dBi linearly polarized antenna |
Read Range |
>12.0m |
Read Mode |
Timing reading , triggering reading, set by software |
Reading Speed |
<6ms per 64 bits, set by software |
picture 1
