Embedded RFID UHF Read Module With Antenna

Name: Embedded RFID UHF Read Module With Antenna
Brand: Mingwah
SKU: 102798431
Availability: InStock

US$ 200 - 250 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Mingwah

Model Number:

MS-X9501 rfid UHF read module

Shandong Mingwah Aohan Smart Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Jinan

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Mingwah

Model Number MS-X9501 rfid UHF read module

Specifications

Embedded RFID UHF Read Module With Antenna
1.One external antenna or antenna built-in
2.With FCC,CE,RoHS
3.Offer free sample

Embedded RFID UHF Read Module With Antenna

Product features

a, Small size can embed in a variety of products need to read and write RFID tags;

b, One external antenna or antenna built-in;

c, ISO18000 6B and 6C double protocol;

d, Multi-programming language SDK, easy to upgrade;

Typical application

Smart traffic management such as: non-stop toll collection, customs clearance, parking management, automatic weighing etc.

Logistics industries such as container management, pallet management, asset tracking etc..

Electronic tickets and personnel access control.

Medical equipment management; medical waste management.

Basic Parameters
Frequency Range	902MHz to 928MHz( Customizable )
Protocols	ISO 18000-6B, ISO18000-6C, EPC Class 1 GEN 2
Work Mode	(FHSS) or fixed frequency, set by software
Antenna	1 external antenna, MMC interface or antenna build-in
Output Rate	20dBm to 30dBm, set by software
Power Flatness	<0.5DB
Read Mode	Commanding reading
Card identification speed	Less than 8ms per card
Read Speed	Read each 8 bytes less than 5ms
Write Speed	Write each 4 bytes less than 25ms
Interface	RS-232 (Customizable)
Power supply	DC 9V / 5V ( Choose one)
Power Consumption	≤5W
Dimensions	70mm×100mm×2mm
Weight	40g
Operation Temp	-10°C~+55°C
Storage Temp	-20°C~+85°C
