Help CenterDouble Mould Tyre Shaping and Curing Press
Related Products
Specifications
1. tyre vulcanizer passed the ISO9001.2.It was sold worldwide in more than 30 countries and regions.
3.made in Qingdao
Good quality with reasonable price. Easy operation with convenient maintenance. Low labor
intensity and low energy consumption.
double mould tyre shaping and curing press
Our factory always adhere to the honesty is the root, a promise is a promise of business philosophy, adhere to the market as the guidance, providing advanced products and high quality service.
Bag o matic type double mould tyre shaping and curing press is suitable for the vulcanization of all- steel heavy duty radialty
Type |
42 |
45 |
48 |
55 |
63.5 |
65.5 |
Mould opening way |
turn |
Horizon/ turn |
Horizon/ turn |
Horizon/ turn |
Horizon/ turn |
Horizon/ turn |
Center mechanism mode |
B |
B |
B |
B |
B |
B |
Mould heating |
Heating plate |
Heating plate |
Heating plate |
Steam pot(heating plate) |
Steam pot(heating plate) |
Steam pot(heating plate) |
Mould quantity |
2 |
2 |
2 |
2 |
2 |
2 |
Max. mould closing force(KN) |
1370x2 |
1720x2 |
1920x2 |
2890x2 |
4220x2 |
4580(4220)x2 |
Mould height(mm) |
155-381 |
230-457 |
250-500 |
245-455 |
254-642 |
254-635 |
Steam hollowware diameter inside |
1050 |
1145 |
1220 |
1310 |
1525 |
1640 |
Apply bead specification |
12-16 |
12-17.5 |
14-20 |
16-20 |
19-24 |
19-24.5 |
Main motor power(kw) |
11 |
11 |
11 |
16 |
16 |
16 |
Overall dimensions LxWxH(mm) |
4252x4410x3916 |
4116x4425x3840 |
5500x3540x3211 |
6108x5380x5590 |
7000x5520x6154 |
7000x5520x5950 |
.
| Contact |
Mr. Gavin Ding Mobile: 0086 13583283100 |
Factory Name Address& Product |
Qingdao Eenor Rubber Machinery Co., Ltd. Binhai Industrial Zone, Jiaonan, Qingdao, China We manufacture and export reclaimed rubber machine, tire recycling rubber powder production line, hydrulic vulcanizing press, rubber extruder, rubber strainer, rubber refiner, rubber tile vulcanizing press, rubber mat machine, conveyor belt production line, conveyor belt jointing press, V belt production line, rotary curing press, rubber kneader, rubber calender, rubber cooling machine, rubber hose production line and other rubber machinery. |
Skype, MSN, G-talk&Email |
Skype: dingqinpeng MSN: dingqp <at> G-talk: dingqinpeng <at> Email: sales27 <at> |
Our motto: The honesty is the root, a promise is a promise.
