remote control parking system 433mhz

Specifications

car access control park barrier
ed for parking system
2.long read range
3.anti-collision

remote control parking system 433mhz





Product Features

*Stable read range>15m. Signal can penetrate the car insulation explosion-proof membrane.

*The read range can be adjusted at the range of 3m to 15m.

*Two read modes: ground pressure triggering read card and automatic read.

*Relay function: control the barrier directly without control panel

*Client password protection: high security.

*Two work modes: manual mode and automatic mode. Automatic mode is applied for open parking lot management system



Specification:

Basic Parameters
Dimensions	280mm×250mm×46mm
Operating Temp	-25°C to +80°C
Humidity	15%HR to 90%HR
Interface	Viegan26/RS-485
Power Supply	DC 12V (±5%)
Environmental Sealing	IP65
RFID Parameters
Type	Read-only
Receive Frequency	433MHz
Transmit Frequency	38KHz
Read Range	3m to 15m (adjustable)
Field	60-degree cone in front of reader
Work Mode	Automatic mode, manual mode
Read Speed	>60 kilometer per hour
Working Current	< 2A

































Disclaimer

The showing pictures are only for your reference of our products. All related to intellectual property rights of trademarks belongs to trademark companies.



SDMW Introduction

As an excellent RFID manufacturer in China, SDMW specializes at RFID handheld readers, RFID fixed readers, RFID antennas and RFID solutions for assets management, logistic management, personnel location management, production line management, high-value commodity anti-counterfeiting etc…

With 15 years RFID experience, SDMW has formed a professional technical team, and cooperate with many famous corporations both home and aboard. Our classic solutions include South Korean Marathon timing system, Kazakhstan payment system, USA warehouse management system etc. SDMW has resellers and distributor in over 55 countries. It takes 80% of domestic market on RFID readers.

We are sure that our experience on serving these tycoons will help us to do better than ever in future!
