Specifications
3 tracks usb magnetic card reader/writer1.Support high swipe speed
2.Multiple record formats compatible
uce damage
3 tracks usb magnetic card reader/writer
Main Parameters
Model |
MW4XX |
Protocols |
ISO7811-7815 |
Decode Mode |
F2F (FM) |
Swipe Speed |
10cm/s to 120cm/s |
Interface |
Keyboard port/RS232/USB |
Magnetic Head Life |
≥50,000times |
Power Supply |
DC 5V±5% |
Operating Temp |
0°C to +45°C |
Humidity |
10%RH to 90%RH |
Ordering Information
Model |
Parameters |
MW401 (R)(U) |
Track 1, keyboard wedge output |
MW402 (R)(U) |
Track 2, keyboard wedge output |
MW403 (R)(U) |
Track 3, keyboard wedge output |
MW412 (R)(U) |
Track1,2, keyboard wedge output |
MW423 (R)(U) |
Track 2,3, keyboard wedge output |
MW433 (R)(U) |
Track 1,2, 3, keyboard wedge output |
SDMW Introduction
As an excellent RFID manufacturer in China, SDMW specializes at RFID handheld readers, RFID fixed readers, RFID antennas and RFID solutions for assets management, logistic management, personnel location management, production line management, high-value commodity anti-counterfeiting etc…
With 15 years RFID experience, SDMW has formed a professional technical team, and cooperate with many famous corporations both home and aboard. Our classic solutions include South Korean Marathon timing system, Kazakhstan payment system, USA warehouse management system etc. SDMW has resellers and distributor in over 55 countries. It takes 80% of domestic market on RFID readers.
We are sure that our experience on serving these tycoons will help us to do better than ever in future!
