Specifications
1.1D/2D wireless mobile handheld pos terminal2.Can connect with portable printer
3.CE FCC ROHS Certificated
4.LF/HF
1D /2D wireless mobile handheld pos terminal
Brief Description
ARM7core@104MHz|MTK6225-JAVA | RAM 64MB/ Flash 128MB | RFID HF ISO14443A/B | 1D Laser and 2D Imager Barcode Scanner | WLAN (IEEE802.11 b/g) | GPRS | Bluetooth | Camera | GPS
Programming Environment
*Java programming
*Software Development Kits (SDK) provided
Application
* Warehouse & Logistics
*Anti-falsification for high value goods
*Assets Management
*Retailing
Performance Characteristics
*CPU: ARM7core 104MHz
*OS: MTK 6225
*Memory: RAM 64MB, Flash 128MB
*Display: 2.8 inch QVGA (240*320 pixel) 64K color TFT-LCD, LED backlight Touch screen is optional
*Key board: 27 keys including 8 customized function keys
*Audio: Bi-Speaker
*SAM: 2 SAM
*Expansion Slot: Support max 4GB TF card
*Battery: 3.7V 1600mAh Lithium battery
*Interface: Mini USB, RS232
*Dimension: 180 x 68 x 33 mm
*Weight: 400g (including battery)
*Temp: Work temp: 0°C - +50°C, Store temp: -20°C - +70°C
*Humidity: 10%RH-85%RH (non-condensing)
*Protection Rate: IP54
*Network Characteristics: GPRS, WIFI, Bluetooth (Option)
*GPS Module: Option
*Call function: Support
*Camera: 2 mega pixels (Option)
*RFID: HF 13.56MHz, ISO14443/ISO15693; LF: 125KHz ISO11784
Example illustration
Product Detail picture
