Help CenterRubber Strainer/rubber Machine
Related Products
Specifications
1-The machine is used for filter rubber2-Model:XJL-115,XJL-150,XJL-200,XJL-250
3-machine head adopt pneumatic control
Good quality with reasonable price. Easy operation with convenient maintenance. Low labor intensity and low energy consumption.
Rubber strainer extruding machine
1.The use introduction
The machine is used for filter rubber .
2. Main technical parameter
|
Model Item |
XJL-115 |
XJL-150 |
XJL-200 |
XJL-250 |
||
Screw dia |
mm |
115 |
150 |
200 |
250 |
|
L/D ratio |
|
4.8 |
5.2 |
5 |
4.8 |
|
Screw speed |
r/min |
40 |
42.5 |
44 |
40 |
|
Cutting equipment speed |
r/min |
15 |
17 |
16 |
6 |
|
Motor power |
kW |
22 |
45 |
75 |
110 |
|
Steam pressure |
MPa |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
|
Cooling water pressure |
MPa |
0.2 |
0.2 |
0.2 |
0.2 |
|
Capacity |
kg/h |
100~280 |
400 |
800 |
1200 |
|
|
Overall dimensions |
L |
mm |
2770 |
3600 |
4229 |
4220 |
W |
mm |
655 |
820 |
2120 |
1400 |
|
H |
mm |
1350 |
1500 |
1493 |
1528 |
|
About weight |
t |
3.5 |
~4.5 |
~8 |
~9 |
|
Above is our standard technical parameter. We can also manufacture NON-STANDARD products according to customers' specific request.
3.Structure introduction
The machine is composed of head, frame, pedestal, pipeline, lubricating system and electrical control system.
Screw is made of 38CrMoALA, the reducer transfers drive through the motor, and screw speed can’t be adjusted. In order to heating or cooling screw, screw is hollow, add steam or cooling water through the rotated joint. Screw is a dicephalous isometry screw thread, and screw thread is wearable owing to the surface of screw thread is heating nitrous treatment. Screw works when the frame is in pressure, and the axial drive is supported by thrust roller axletree in thrust axletree bedplate .
