Help Center12V 60W 5A Switching Led Power Supply
Related Products
-
Constant Voltage Led Switching Power SupplyNegotiableMOQ: 100 Pieces -
3.3V 30A 150W Switching Led Power SupplyNegotiableMOQ: 100 Pieces
-
12V 12.5A Switching Led Power SupplyNegotiableMOQ: 100 Pieces
-
AC85-264V 47-64Hz Constant Voltage Switching Led Power SupplyNegotiableMOQ: 100 Pieces
-
AC85-264V 47-64Hz 150w Switching Led Power SupplyNegotiableMOQ: 100 Pieces
Specifications
12V 60W 5A Switching led power supply1.high energy saving
2.CE,RoHs cetificate
3.green products
12V 60W 5A Switching led power supply
Input Voltage:AC85-264V 47-63Hz
Operation Range:AC90-250V
Output Voltage :DC12±15% V
Output Current:5.0A
output Power:DC60Wmax
Dimension:160X98X38MM
Weight:375G/PCS(Carton Package)
Rise hold up time:50ms,20ms at full load(Typical)
Hi-pot lsolation:I/P-O/P 3KVAC,I/P-FG 1.5KVAC,O/P-FG0.5KVAC
Safety Standards:TUV EN60950-1
Remark:(Constant Voltage Source)CE/ROHS
Model
Output Specification
Noise
Efficiency
JJW-60-3.3
3.3V
12A
50mW
66%
JJW-60-05
5V
12A
60mW
76%
JJW-60-09
9V
6.6A
60mW
78%
JJW-60-12
12V
5.0A
60mW
80%
JJW-60-15
15V
4.0A
60mW
80%
JJW-60-24
24V
2.5A
60mW
80%
JJW-60-28
28V
2.1A
60mW
80%
JJW-60-36
36V
1.7A
60mW
80%
JJW-60-48
48V
1.25A
60mW
82%
led power supply Features:
1.High efficiency and with PFC
2.Energy-saving and safety
3.CE and ROHS certificate
4.PWM switch design,efficiency power exceeds 85
5.Dissipating by natural air flow
6.100 full load aging testing
