LED power supply1,High quality,competitive price,fast delivery
2,1 year warranty
3,Samples and minimum order are available
150W 36V 4.2A non-waterproof LED power supply
1,High quality,competitive price,fast delivery
2,1 year warranty,
3,Samples and minimum order are available
Features:
1) AC input range selectable by switch
2) Cooling by free air convection
3) LED indicator for power on
4) Short circuit, over load, over voltage protections
5) 100% full load burn-in test
6) High efficiency, long life and high reliability
7) Universal AC Input
Input Voltage:AC85-264V 47-63Hz
Operation Range:AC90-250V
Output Voltage :DC36±15% V
Output Current :4.2A
Output Power :DC150Wmax
Dimension:199X98X38MM
Weight:560G/PCS(Carton Package)
Rise hold up time:50ms ,20ms at full load(Typical)
Hi-pot lsolation :I/P-O/P 3KVAC,I/P-FG 1.5KVAC,O/P-FG0.5KVAC
Safety Standards:TUV EN60950-1
Remark:(Constant Voltage Source)CE/ROHS
Model | Output Voltage | Output Current | Output Power | Efficiency |
| JJW-150-3.3 | 3.3V | 30A | 150W | 66% |
| JJW-150-5 | 5V | 30A | 150W | 76% |
| JJW-150-9 | 9V | 16.5A | 150W | 78% |
| JJW-150-12 | 12V | 12.5A | 150W | 80% |
| JJW-150-15 | 15V | 10A | 150W | 80% |
| JJW-150-24 | 24V | 6.5A | 150W | 80% |
| JJW-150-28 | 28V | 5.35A | 150W | 80% |
| JJW-150-36 | 36V | 4.2A | 150W | 80% |
| JJW-150-48 | 48V | 3.3A | 150W | 82% |
