Help CenterFour-roll Rubber Calendar Machine
Related Products
Good quality with reasonable price. Easy operation with convenient maintenance. Low labor intensity and low energy consumption.
The machine is mainly used for sheeting of rubber.
The calendar is used for calendering rubber & plastic.
Rubber calender advantages
1.The rolls are made of chilled cast iron with vanadium and titanium alloys. The roll face is hard and anti-wear. To heat up or cool down, the rolls are either circumferentially drilled or centrally bored so as to make temperature well proportioned on the roll surface.
2.The transmission system adopts a hard facing gear reducer, which has a compacted structure with higher transmission efficiency, lower noise and longer service life.
3. The machine is equipped with emergency device. When an emergent accident occurs, the calendar will be immediately stopped to open the roll space so as to protect the operator and equipment. PLC program controller is used in electric system.
Specifications:
| Model | XY-3I 630 | XY-3I 1120A XY-3 1120A XY-3l1120A |
XY-3I 1400 | XY-3I 1200 XY-3I 1500 |
XY-3I 1730 | XY-3I 2130 |
| Roll diameter (mm) | 230 | 360 | 400 | 450 | 610 | 710 |
| Roll working length (mm) | 630 | 1120 | 1400 | 1200(1500) | 1730 | 2130 |
| Roll speed ratio | 1: 1: 1 1: 1.42: 1 |
1: 1: 1 0.733: 1: 1 0.733: 1.0.733 |
1: 1: 1 1: 1.383: 1.383 1: 1.383: 1 |
1: 1: 1 1: 1.5: 1 |
1: 1: 1 1: 1.4: 1 |
1: 1: 1 1: 1.48: 1 |
| Middle-roll linear speed (m/min) | 7.97 | 7.0-21.06 | 8.8-26.39 | 8.36-25.08 | 5.4-54 | 8-50 |
| Adjusting nip range (mm) | 0-7 | 0-10 | 0-10 | 0-6 | 0-20 | 0-20 |
| Min. Calendering product thickness (mm) | 0.2 | 0.2 | 0.2 | 0.15 | 0.15 | 0.15 |
| Calendering product width (mm) | 100-500 | 500-920 | 1200 | 1100(1400) | 1500 | 1900 |
| Motor power (kw) | 7.5 | 40/13.3 | 55/18.3 | 75/25 | 132 | 185 |
| Overall dimensions (mm) | 2570× 740× 1500 | 5550× 1640× 2120 | 6500× 1500× 2440 | 7120(7420)× 2200× 2900 | 7010× 3950× 3730 | 7650× 4560× 4080 |
| Weight (kg) | 4200 | 12750 | 26000 | 27000 | 52000 | 67000 |
Above is our standard technical parameter. We can also manufacture NON-STANDARD products according to customers' specific requests.
Rubber calender structures:
1.The machine consists of bedplate, frame , rolls , motor , coupling ,speed–ratio gear , adjusting spacing device , the adjusting temperature device of rolls.
2.The bedplate is a whole model for Installation convenience.
3.Roll are made of chilled case alloy iron. The working surface of roll is hardness and smooth. Steam and cooling water can pass through inner of the rolls so that surface temperature can be adjusted.
4.Roll bearing, high precision, long service life.
5.Adjusting spacing device consists of one left and one right hand wheel. The bearing bases can be moved to adjust the nip by worm and worm wheel.
..
