Home > Products > Hydraulic Rubber Hose > 3/8" SAE 100r2/2sn Hydraulic Rubber Hose for Construction
3/8" SAE 100r2/2sn Hydraulic Rubber Hose for Construction
- 100000 Meter / Meters per Month
- Ningbo or Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | PASSION OF R2 Hydraulic Rubber Hose | Model Number: | SAE100 R2 Hydraulic Rubber Hose |
Product Description
3/8" SAE 100r2/2sn Hydraulic Rubber Hose for Construction
SAE 100R2 AT/EN853 2SN(cloth wrapped surface)
Construction: Tube: NBR synthetic rubber.
Reinforcement: Two layers of high-tensile steel wire braided.
Cover: NBR oil and weather resistant synthetic rubber.
Temperature: -40℃ - +100℃
Color: Black.
Application: Mainly used for conveying of petroleum or water based hydraulic fluids in mobile, machine tool, agricultural applications etc.
Standard length: 100m, 50m, 40m, 20m.
Specification:
Item Code | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Length | Measurement | Weight | |||
inch | mm | mm | bar | psi | bar | psi | m | cbm/roll | kg/m | |
R1-05 | 3/16 | 4.8 | 12.3 | 414 | 6000 | 1655 | 24000 | 100 |
| 0.32 |
R1-06 | 1/4 | 6.4 | 15.5 | 400 | 5800 | 1600 | 23200 | 100 | 0.0514 | 0.37 |
R1-08 | 5/16 | 8.0 | 16.5 | 350 | 5075 | 1400 | 20300 | 100 | 0.0612 | 0.412 |
R1-10 | 3/8 | 9.5 | 19.5 | 331 | 4800 | 1324 | 19200 | 100 | 0.0784 | 0.53 |
R1-13 | 1/2 | 12.7 | 22.5 | 276 | 4000 | 1103 | 16000 | 100 | 0.0833 | 0.64 |
R1-16 | 5/8 | 16.0 | 25.5 | 250 | 3630 | 1001 | 14520 | 50 | 0.074 | 0.77 |
R1-19 | 3/4 | 19.0 | 29.5 | 215 | 3120 | 860 | 12480 | 50 | 0.0833 | 0.96 |
R1-25 | 1 | 25.4 | 38.1 | 165 | 2400 | 662 | 9600 | 50 | 0.1445 | 1.35 |
R1-32 | 1 1/4 | 32.0 | 48.0 | 125 | 1820 | 502 | 7280 | 20 | 0.209 | 2.05 |
R1-38 | 1 1/2 | 38.0 | 55.0 | 90 | 1310 | 361 | 5240 | 20 | 0.2509 | 2.511 |
R1-51 | 2 | 50.8 | 68.6 | 80 | 1160 | 320 | 4640 | 20 | 0.3796 | 3.165 |
About Us:
<passion>
High quality products, Low prices, Convenient payment procedure
We are a leading manufacturer specialized in designing and manufacturing various kinds of rubber hoses and hydraulic high pressure in China with experience more than 10 years, manufacturing in accordance ISO 9001: 2008, ISO / TS CE, 29001 and API Q1. We help our clients to develop special qualities and hydraulic rubber hose for their needs.
Factory of Hydraulic Rubber Hose:
Q1. Do you produce smooth or cloth wrapped cover?
A. Both, we can produce both cover, which depends on customer’s request.
Q2. Do you produce embossed marking?
A. Yes, we do provide embossed and printing markings with different color.
Q3. Can you produce product with my own brand?
A. Yes, we can offer OEM services.
