Specifications
hydraulic hose assembly1. Ferrull is tight to the hose
2. Manufacturer
3. CE Certificate
Hydraulic Hose Assembly, Hydraulic Rubber Hose
Application: High pressure hydraulic oil lines used in
construction, machine tool and agricultural
applications using petroleum or water
based hydraulic fluids
Inner Tube: Nitrile
Reinforcement: Two braids of high-tensile steel wire
Cover Compound: Neoprene
Temperature Range: -40°C ~ +100°C
part |
In |
Hose Size ID DIN Dash Size |
Hose OD |
Max.Working pressure |
Min.Bend Radius |
Min..burst pressure |
Weight (ibs/foot) |
||||
in |
mm |
psi |
mpa |
in |
mm |
psi |
mpa |
||||
GR2SN-03 |
3/16 |
4.8 Din Dash size |
0.484 |
12.3 |
6000 |
41.4 |
3.5 |
89 |
24000 |
165.5 |
0.2 |
GR2SN-04 |
1/4 |
6.4 Din Dash size |
0.593 |
15.1 |
5800 |
40 |
4 |
102 |
23200 |
160 |
0.24 |
GR2SN-06 |
3/8 |
9.5 Din Dash size |
0.753 |
19.1 |
4800 |
33.1 |
5 |
127 |
19200 |
132.4 |
0.34 |
GR2SN-08 |
1/2 |
12.7Din Dash size |
0.875 |
22.2 |
4000 |
27.6 |
7 |
178 |
16000 |
110.3 |
0.43 |
GR2SN-10 |
5/8 |
15.9 Din Dash size |
1 |
25.4 |
3630 |
25 |
8 |
203 |
14520 |
100.1 |
0.5 |
GR2SN-12 |
3/4 |
19 Din Dash size |
1.157 |
29.4 |
3120 |
21.5 |
9.5 |
241 |
12480 |
86 |
0.61 |
GR2SN-16 |
1 |
25.4 Din Dash size |
1.5 |
38.1 |
2400 |
16.5 |
12 |
305 |
9600 |
66.2 |
0.88 |
GR2SN-20 |
11/4 |
31.8 Din Dash size |
1.877 |
47.7 |
1820 |
12.5 |
16.5 |
419 |
7280 |
50.2 |
1.2938 |
GR2SN-24 |
11/2 |
38.1 Din Dash size |
2.129 |
54.1 |
1310 |
9 |
20 |
508 |
5240 |
36.1 |
1.6134 |
GR2SN-32 |
2 |
50.8 Din Dash size |
2.627 |
66.7 |
1160 |
8 |
25 |
635 |
4640 |
32 |
1.9825 |
