J1402 Rubber Air Brake Hose
Hose Construction
Inner Tube: Black, Smooth, NBR/SBR Rubber Compound.
Reinforcement: Synthetic textile yarns.
Cover: Black, smooth, abrasion, ageing
and weather-resistant CR rubber compound.
Applications:
Widely used in automotive air brake systems.
Temperature Range:
-40 °C (-40 °F) to + 93 °C (+200 °F).
Tolerances:
According to SAE J1402 – TABLE A
Technical Specifications:
|
Size
|
I.D. (inch) |
I.D. (mm) |
O.D (mm) |
Wall(mm) |
Wall Diff (mm) |
W.P. Max.Mpa |
B.P. Min Mpa |
5 |
3/16" |
5±0.2 |
14±0.3 |
3.50 |
<0.3 |
1.1 |
>12 |
6 |
1/4" |
6±0.2 |
15±0.4 |
4.50 |
<0.3 |
1.1 |
>12 |
8 |
5/16" |
8±0.2 |
15±0.3 |
3.50 |
<0.3 |
1.1 |
>12 |
10 |
3/8" |
10±0.3 |
17±0.4 |
3.75 |
<0.3 |
1.1 |
>12 |
13 |
1/2" |
13±0.3 |
23±0.4 |
3.50 |
<0.4 |
1.1 |
>12 |
14 |
9/16" |
14±0.3 |
23.5±0.4 |
3.80 |
<0.4 |
1.1 |
>12 |
16 |
5/8" |
16±0.3 |
24±0.4 |
4.00 |
<0.4 |
1.1 |
>12 |
With 10 years' experience, Passion Hoses are now exporting to Countries all over the world.
The main market is America, Britain, Australian, UAE, Canada , Brazil and so on.
