hydraulic hose fitting assembly

part

In

Hose Size ID DIN Dash Size

Hose   OD

Max.Working pressure

Min.Bend Radius

Min..burst pressure

Weight

(ibs/foot)

in

mm

psi

mpa

in

mm

psi

mpa

GR1SN-03

3/16

4.8 Din Dash size

0.47

11.9

3630

25

3.5

89

14520

100.1

0.12

GR1SN-04

1/4

6.4 Din Dash size

0.534

13.6

3270

22.5

4

102

13080

90.2

0.15

GR1SN-05

5/16

7.9 Din Dash size

0.595

15.1

3120

21.5

4.5

114

12480

86

0.17

GR1SN-06

3/8

9.5 Din Dash size

0.689

17.5

2615

18

5

127

10460

72.1

0.22

GR1SN-08

1/2

12.7 Din Dash size

0.813

20.7

2320

16

7

178

9280

64

0.28

GR1SN-10

5/8

15.9 Din Dash size

0.938

23.8

1890

13

8

203

7560

52.1

0.33

GR1SN-12

3/4

19 Din Dash size

1.096

27.8

1530

10.5

9.5

241

6120

42.2

0.41

GR1SN-16

1

25.4 Din Dash size

1.408

35.8

1280

8.8

12

305

5120

35.3

0.62

GR1SN-20

11/4

31.8 Din Dash size

1.696

43.1

920

6.3

16.5

419

3680

25.4

0.8368

GR1SN-24

11/2

38.1 Din Dash size

1.971

50.1

730

5

20

508

2920

20.1

1.0921

GR1SN-32

2

50.8 Din Dash size

2.503

63.6

580

4

25

635

2320

16

1.3413
