Help Center3/8'' SAE J1402 Flexible Fiber Braided Rubber Air Brake Hose
Related Products
-
DOT Certificate Fiber Braided Flexible Brake Hose for AutomobileUS$ 5.6 - 7MOQ: 200 Pieces -
DOT Certificate 1/8'' SAE J1401 Brake HoseUS$ 5.6 - 7MOQ: 200 Pieces
-
Fiber Braided Flexible Rubber Air Brake Pipe Assembly With SAE J1402 StandardUS$ 5.5 - 8MOQ: 500 Pieces
-
SAE J1402 Fiber Braided Flexible Rubber Air Brake Hose Tubing Assembly for MotorycleUS$ 5.5 - 8MOQ: 500 Pieces
-
1/8'' SAE J1401 Hydraulic Brake Hoses for CarUS$ 5.6 - 7MOQ: 200 Pieces
3/8 Air Brake Hose
Hose Construction
Inner Tube: Black, Smooth, NBR/SBR Rubber Compound.
Reinforcement: Synthetic textile yarns.
Cover: Black, smooth, abrasion, ageing
and weather-resistant CR rubber compound.
Applications:
Widely used in automotive air brake systems.
Temperature Range:
-40 °C (-40 °F) to + 93 °C (+200 °F).
Tolerances:
According to SAE J1402 – TABLE A
Technical Specifications:
|
Size
|
I.D. (inch) |
I.D. (mm) |
O.D (mm) |
Wall(mm) |
Wall Diff (mm) |
W.P. Max.Mpa |
B.P. Min Mpa |
5 |
3/16" |
5±0.2 |
14±0.3 |
3.50 |
<0.3 |
1.1 |
>12 |
6 |
1/4" |
6±0.2 |
15±0.4 |
4.50 |
<0.3 |
1.1 |
>12 |
8 |
5/16" |
8±0.2 |
15±0.3 |
3.50 |
<0.3 |
1.1 |
>12 |
10 |
3/8" |
10±0.3 |
17±0.4 |
3.75 |
<0.3 |
1.1 |
>12 |
13 |
1/2" |
13±0.3 |
23±0.4 |
3.50 |
<0.4 |
1.1 |
>12 |
14 |
9/16" |
14±0.3 |
23.5±0.4 |
3.80 |
<0.4 |
1.1 |
>12 |
16 |
5/8" |
16±0.3 |
24±0.4 |
4.00 |
<0.4 |
1.1 |
>12 |
Packing
1. We will provide you with accurate, detailed Quotation.
2. We will offer you reliable shipping agent for reference.
3. The package will be stout based on your request.
5. The product will be delivered timely based on the lead-time.
