CR1220 Lithium Battery

Specifications

CR1220-1VC 3V lithium coin cell tabs battery with pins
weld soldering battery
tabs can be make as customer's request









1. Varieties of models ranging from CR1025, CR1025, CR1225, CR1616, CR1620, CR1620, CR2016, CR2025, CR2032, CR2430, CR2450 ect.

2. Wide operating temperature range from -20C to 60C

3. Long service life and Environmentally friendly

4. Meet the requirement of European markets

5. high capacity, safe and stable, comprehensively complying with ROHS standard and 2006/66/EC standard.

Application: wristwatches, computers, music cards, medical instruments, PDA, MP3,shoe lamps, card-style radio, IC Card and othe electronic product .



Model	Nominal Voltage(V)	Nominal Capacity (mAh)	Dimensions (mm)	Weight(g)
CR927	3.0V	30	9.5X2.7mm	0.6g
CR1025	3.0V	25	12.5X1.6mm	0.6g
CR1220	3.0V	40	12.5X2.0mm	0.8g
CR1616	3.0V	50	16.0X1.6mm	1.2g
CR1620	3.0V	70	16.0X2.0mm	1.3g
CR1632	3.0V	120	16.0X3.2mm	1.6g
CR2016	3.0V	75	20.0X1.6mm	1.6g
CR2025	3.0V	150	20.0X2.5mm	2.4g
CR2032	3.0V	210	30.0X3.2mm	3.1g
CR2320	3.0V	130	23.0X2.0mm	2.9g
CR2330	3.0V	260	23.0X3.0mm	4.0g
CR2354	3.0V	530	23.0X5.4mm	6.3g
CR2430	3.0V	270	24.5X3.0mm,	4.3g
CR2450	3.0V	550	24.5X5.0mm	6.2g
CR2477	3.0V	1000	24.5X7.7mm,	10.0g
CR3032	3.0V	560	30.0X3.2mm	8.0g
