2015 new cheap mini ip pbx gsm fixed wireless terminal for pbx
WS824 (3)i,besides equipped with traditional switch function, also support the dual mode of computer operator, the extension number, automatic economic routing, mobile account management, Check list extension information, and other functions,and allow the user to get new experience of switch function, improve office efficiency.
Main Function
Can be connected with 4 key phones
System programmed and monitored by key phone easily.
Built-in 6 duration Out-Going Message
Built-in Caller ID function for intercom and outside Line number and number can be transferred display again and again.. An incoming calls number can be displayed at 5 extensions at same time.
Economical Code auto-route
Select a CO Line directly without dialing digit “9”.
Day/Night Service manually
Flexible Extension Numbering
255 groups Walking Account Code
Manger/Secretary Call-group
3-party Conference Call
Hot Dialing
Auto call back on busy
Multi-answer Mode
Call Forward
Setting Operator
Extension lock
Call Pick-up
Conversation Time Alarm
Interrupt and disconnect an outside call
IP PBX Function
System TFTP upgrade
Data backup and restore
WEB remote interface management
Multiple voice codec format (A,U,iLBC,G729)
50 IP extension Account
4 Traditional voice concurrent channel
20 IP platform concurrent calls
IP voice calls bypass
IP extension account, IP trunking support SIP Type
Flexible networking
DID number across the equipment through the call
Resonance
IP call extension account level limite
Relay equipment sharing
Pass through the number
General IP phone support
Open standard interface protocols
Specification Parameter
Size | 310*191*82mm |
Weight | 2kgs |
FXS(PSTN) | 16 |
FXO+FXS | 4 |
CDMA/GSM | Optional |
IP user | 50 |
IP concurrent | 20 |
IP and Traditional voice concurrent channel | 4 |
SIP trunk | 9 |
LANPort | 1 |
SIP Protocol | YES |
Record | Optional |
Power Supply
Power supply voltage: 110VAC or 220 VAC,50/60 Hz
Maximum power consumption: 30W
Cross-talk attenuation: >70db
Internal feeding voltage: +28VDC, 30mA
Internal ringing voltage:75VAC/50Hz
External line port voltage: <60VDC
External line port ringing voltage: 35VAC/25Hz or >35VAC/50Hz
performance parameter
Power supply voltage: 220 VAC,50/60 Hz
Maximum power consumption: 35W
Cross-talk attenuation: >70db
Internal feeding voltage: +28VDC, 30mA
Internal ringing voltage:75VAC/50Hz
External line port voltage: <60VDC
External line port ringing voltage: 35VAC/25Hz or >35VAC/50Hz
Environmental Limits
Operating temperatures: 0°C to 45°C (32°F to 113°F)
Operating humidity: 10% to 95% without condensation
