Product Details
Place of Origin: | Guangdong, China | Brand Name: | Cesller or OEM | Model Number: | NSN9000Si voip gateway |
Type: | Other, VoIP Gateway, fxs gsm gateway |
Product Description
Best quality high range voip gateway fxs/VOIP router
1. Built-in Caller ID function for intercom and outside Line.
2. Busy Tone of Co Line Detection.
3. Support message light function.
4. Morning call function.
5. Co.Line Gain Adjustment(Co Line Gain can be reached to 3dB.)
6. Reverse polarity of Co line Detection.
7. Trunk number intergrated. ( need the support of telecommunication operator)
8. Operator can use the phone recording or recording interface to an external music
9. External music source inferface.
10.Voice report extension number or extension physical number.
11.Abbreviated code 100 group.
12.Multi-party conference call(support 2 group 3 party conference at most.
13.Paging function:Paging tone,there are two options.
14.Key phone group call.
15. Multi Answer Mode.
16. Interrupt ,disconnect a call and monitoring function.
17. 255 groups Walking Account Code.
18. .Day/Night Service manually.
19. Conversation Time Alarm.
20. Co line special call restriction.
21.Day/Night Exts to Co lines limition
22.Exts to Exts limition call
23 6 classes of serive.
24. Extension number can be numbered flexibly(from 2 digits to 4 digits), and the leading number can be “1”,“2”,“8”.
25. Multi-station tion.
26.No one answer/hold recall
27.Hot-call dialing
28.Incoming call limition.
29.Pick-up call
30. Manager-Secretary function.
31.Extension or mobile account.
32.Call forward
33.Inside/outside busy booking function.
34.UPS function
IP Function
1.System TFTP upgrade
2.Data backup and restore
3.WEB remote interface management
4.Multiple voice codec format
5.300 IP extension Account
6.30 TDM-IP concurrent access
7.40 IP platform concurrent calls
8.IP voice calls bypass
9.IP extension account, IP trunking support SIP Type
10.Flexible networking
11.DID number across the equipment through the call
12.Resonance
13.IP call extension account level limite
14.Relay equipment sharing
15.Pass through the number
16.General IP phone support
17.Open standard interface protocols
18.High system integration
Specification Parameter
Model | NSN9000Si | NSN9000Mi |
Size | 435*265*140mm | 435*311*368mm |
FXS | 144 | 312 |
FXS(PSTN) | 32 | 64 |
E1 | 1 | 4 |
FXS+FXO | 144 | 312 |
E1+FXS | 1E1+136 | 4E1+280 |
CDMA/GSM | YES | YES |
Number of IP user | 300 | 300 |
Number of IP concurrent | 40 | 40 |
Concurrent IP and TDM channel | 4+26(optional) | 4+26(optional) |
Number of SIP trunk | 30 | 30 |
LANPort | 1 | 1 |
SIP Protocol | YES | YES |
Record(TDM) | Optional | Optional |
Technical Specification
Model | NSN9000Si | NSN9000Mi |
AC input | 110VAC/220VA±10%/50Hz-60Hz | 110VAC/220VA±10%/50Hz-60Hz |
Internal feeding voltag | +48VDC/30mA | +30VDC/25mA |
Internal ringing voltage | 75VAC/25Hz | 75VAC/25Hz |
Backup battery voltage | +24VDC | +24VDC |
Exts line port voltage | <60VDC | <60VDC |
Exts line port ringing voltage | >35VAC/25Hz/>35VAC/50Hz | >35VAC/25Hz/>35VAC/50Hz |
System power voltage | 85W | 150W |
Line impedance | 600Ω | 600Ω |
Input level | 250MV, max 1V RMS | 250MV, max 1V RMS |
Exchange mode | TDM+IP | TDM-IP |
Enviroment temperature | 0-45℃(32-113℉),25±5°Best | 0-45℃(32-113℉),25±5°Best |
Enviroment humidity | 10%-95% noncondensing | 10%-95% noncondensing |
Exts lines with Caller ID display |
FSK |
FSK |
Co lines with Caller ID display | DTMF/FSK | DTMF/FSK |
Detection sensitivity | 01-33db(nosie<-3-db) | 01-33db(nosie<-3-db) |
Exts failure time effectively | 80ms-800ms | 80ms-800ms |
Dial tone | ||
Busy tone | ||
Invalid sound | Single frequency 440Hz,0.25s open,0.25s break, Cycle 0.5s | |
Ring-back tone | Single frequency 440Hz,1s open,4s break, Cycle 5s | |
4 core key phone | <100m(0.4@ twisted two pair,impedance<22.5Ω
| |
2 core key phone | <1500m(0.5@ twisted two pair,impedance<200Ω
|
Common phone | <1000m(0.4@ twisted two pair,impedance<225Ω
|
Billing wires | <30M |
Shenzhen Guowei Cesller Technology Co.,Ltd,our headquarter lies in Canada. It is a hi-tech. Company, specializing in manufacturing, developing, selling of group-phone system and communication equipments. The managing idea is to provide continually communication products which joint global communication and synchronize to world communication.
Shipping to worldwide by DHL, FEDEX, TNT and UPS etc.
