1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape

1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape thumbnail-1
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape thumbnail-2
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape thumbnail-3
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape thumbnail-4
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape thumbnail-5
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape thumbnail-6
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape photo-1
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape photo-2
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape photo-3
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape photo-4
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape photo-5
1260C 550K Ceramic Fiber Tape for Furnace Curtains Ceramic Fiber Tape Ceramic Weld Backing Tape photo-6
Negotiable MOQ: 100 Rolls (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Application:
Refractory, Fireproof Material
Thickness:
2-10mm
Width:
20-150mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Thickness 2-10mm
Width 20-150mm
Length 3000mm
Grade ST (Standard)
Chemical Composition AL2O3≥45%, AL2O3+SiO2≥97%
Working Temperature 1200℃
Fiber Diameter 3μm
Thermal Conductivity 0.17
Shrinkage (1800℉, 3h) <3%
Place of Origin Shandong, China
Brand Name YAOXING
Model Number YXTX-208B2

Product Description

 1260C 550K Ceramic Fiber Tape for Furnace curtains



 Characteristic



1.Excellent high-temperature strength

2.Excellent electric insulation capability

3.Excellent corrosion resistance to acid, oil and steam

4.Low thermal conductivity

5.Excellent thermal insulation capability



 Technical Index



Classification Temperature

1260

Product

1260 ceramic fiber cloth

1260 ceramic fiber tape

Code

YXTX-208A1

YXTX-208A2

YXTX-208B1

YXTX-208B2

Service

Temperature(°C)

450

1000

450

1000

Basic Material

Ceramicfiber/

glass fiber

 reinforced

Ceramic fiber/

stainless steel

reinforced

Ceramic fiber/

glass fiber

reinforced

Ceramic fiber/

stainless steel

 reinforced

Theoretical

Density

(kg/m3)

400-500

550-630

550

Specification (mm)

3000×1000/1500×2/3

3000×20/50/75/100×2/3

Moisture Content(%)

≤2

Warp Density

56-60piece/10cm

Weft Density

24-30piece/10cm

Organic Content (%)

≤15



Applications



1.Furnace curtains



2.Protection against high temperature



3.High temperature electrical insulation



4.Cable and fuel line protection



5.Fire protection



6.Insulation of industrial chimney



1260C 550K ceramic fiber tape for furnace curtains ceramic fiber tape ceramic weld backing tape1260C 550K ceramic fiber tape for furnace curtains ceramic fiber tape ceramic weld backing tape1260C 550K ceramic fiber tape for furnace curtains ceramic fiber tape ceramic weld backing tape
