ceramic fiber sleeve

Specifications

Excellent thermal insulation capability
Noted for high temperature resistant up to 1260C
Low thermal conductivity

Ceramic fiber  sleeve
Classification temperature	1260
Product	1260 ceramic fiber sleeve
Code	TXTX-208F
Service temperature(°C)	1000
Basic material	Ceramic fiber/glass fiber reinforced
Theoretical density (kg/m3)	500±15
Moisture content(%)	≤1
Delivery state	Roll
Organic content (%)	≤2



Characteristic:



Excellent high-temperature strength

 Excellent electric insulation capability

 Excellent corrosion resistance to acid, oil and steam

Low thermal conductivity

Excellent thermal insulation capability

Noted for high temperature resistant up to 1260C,

Ceramic fiber textiles feature:

Excellent properties of lightweight, low thermal conductivity and chemical stability resisting attack from most corrosive agent.

Ceramic fiber sleeves are widely used in thermal insulation industry.

Ceramic sleeves are made of ceramic fiber woven yarns with fiberglass yarn or steel wire reinforcement.

Wall-thickness(mm)	Reinforcement	Work Temp.
2mm-3mm	With Fiberglass	650
2mm-3mm	With steel wire	1050,1260







Application:



     Used in high temperature resistant electrical cable, wire covering—High temperature tubes wrapping
