Ceramic Fiber Shape Hard Board for Steel Mill

Name: Ceramic Fiber Shape Hard Board for Steel Mill
Brand: YAOXING
SKU: 102724355
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Application:

Heat Insulation, Fireproof Material

Grade:

HZ (High Zirconium)

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Grade HZ (High Zirconium)

Chemical Composition AL2O3≥38%,ZirO2≥15%

Working Temperature 1400℃

Fiber Diameter 3μm

Thermal Conductivity <3%

Shrinkage (1800℉, 3h) 0.060-0.070

Brand Name YAOXING

Model Number YXTX-755

Specifications

Ceramic fiber special-shaped products
Excellent refractory and insulation
contacting with fire directly
Density:280kg/m3

Technical Index:

Classification Temperature		1260	1400		1600
Code		YXTX-255	YXTX-455	YXTX-555	YXTX-755
Shrinkage on Heating (%)		1000°C×24h ≤-3	1200°C×24h ≤-3	1350°C×24h ≤-3	1400°CX24h ≤-3
Theoretical Thermal Conductivity (W/m·k)	(200°Caverage) (400°Caverage) (600°Caverage)	0.055-0.065 0.110-0.120 0.160-0.170			0.060-0.070 0.105-0.125 0.170-0.180
Density(kg/m3)		300-500
Specification		According to your requirements
Packing		Wooden Boxes or Cartons

Application

Electric equipment:

insulation, high-temperature material for industrial furnaces,
ladles and submerged nozzle.
Asbestos backup.Expansion joint sealing and filling insulation(vehicle,pipeline, door and so on),the ceramic fiber lining for high temperature furnaces or heating equipment.
Inspecting hole in industry furnace,expansion joint,
Furnace door the burner set piecesand inserting hole of thermometer
