Gasket Fire Resistant Paper

Gasket Fire Resistant Paper thumbnail-1
Gasket Fire Resistant Paper photo-1
Negotiable MOQ: 20 Rolls (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Application:
Heat Insulation
Thickness:
0.5-7mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Application Heat Insulation
Thickness 0.5-7mm
Width 610/1200mm
Length 12000-100000mm
Grade ST (Standard)
Chemical Composition AL2O3 SIO2
Working Temperature 1100
Fiber Diameter 3um
Thermal Conductivity 0.075
Shrinkage (1800℉, 3h) ≤3%
Brand Name Yaoxing
Model Number YXTX-236

Specifications

610mm 1220mm width ceramic fiber paper
0.5-7mm thickness any length
1260C 1400C
density 180-200kg/m3

Product Series:

1.1260 Ceramic Fiber Paper YXTX-236

2.  1400 Ceramic Fiber Paper YXTX-336

 gasket fire resistant paper

Description:

1. YAOXING Ceramic Fiber Paper is processed from the high purity fiber, which can be used in the field of high temperature insulation. Because we have adopted the advanced processing work, we cannot only make the fiber interweave shapely, but also can control the thickness and the density rigidly.

2. A spot of bonding agent has been added into the fiber during processing, which has been chosen and controlled scientifically, can be burnt during application.



Characteristic:

1. Low Heat Storage

2. Low Thermal Conductivity

3. Excellent Thermal Electrical Insulation

4. Excellent Machine-processed Capability

5. Excellent Broken Resistance

6. Excellent Flexibility

7. Low Shot Content



Application:

1. Industrial insulating ,sealing and protecting materials

2. Electric and thermal insulation materials for electric industry

3. Insulation materials for instrument-equipment

4. Insulating materials for motor industry

5. Filling materials for expansion slot

6. Insulating materials as the sinter resistance

7. Sealing gasket for molten metal

8. Fireproof materials





Technical Index:



Classification Temperature

1260

1400

Name

ST Ceramic Fiber Paper

HZ Ceramic Fiber Paper

Code

YXTX-236

YXTX-336

Shrinkage on Heating (%)

1000°C×24h ≤-3

1350°C×24h≤-3

 Theoretical

Thermal Conductivity

(W/m·k)

(200°Caverage)

(400°Caverage)

(600°Caverage)

0.075-0.085

0.110-0.121

0.160-0.170

Organic Content (%)

≤ 10

≤ 8

Theoretical Density (kg/m3)

200±15

Tensile Strength (Mpa)

≥0.3

≥0.2

Moisture Content(%)

≤1

Specification (mm)

100000/12000×610/1220×0.5/7,

According to your requirements

Package

Plastic Bag Inside, Carton Box Outside

Quality Control System

ISO9001-2000, ISO14001-1996

 gasket fire resistant papergasket fire resistant papergasket fire resistant paper
