WF67K-500/6000 CE Cnc Metal Plate Bending Machine Quality Choice
US$ 125,767 - 131,267
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Liaoning, China
Brand Name:
LFM
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian/Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WE67K-400/6120 Electro Hydraulic Cnc Plate Bending Machine for SaleUS$ 108,500 - 109,302MOQ: 1 Set -
CE Hydraulic Plate Bending MachineUS$ 7,273 - 64,804MOQ: 1 Set
-
WF67Y-200/10000 CE Four Cylinder Hydraulic Metal Plate Bending MachineUS$ 679,000 - 679,860MOQ: 1 Set
-
CE Hydraulic Plate Bending MachineUS$ 13,173 - 64,804MOQ: 1 Set
-
WE67K-125/3200 CE Electro Hydraulic Cnc Plate Bending MachineUS$ 45,800 - 46,000MOQ: 1 Set
Condition
New
Place of Origin
Liaoning, China
Brand Name
LFM
Model Number
WF67K-500/6000 cnc plate bending machine
Machine Type
Roll Forming Machine
Raw Material
Sheet / Plate Rolling
Material / Metal Processed
Stainless Steel
Power
Cnc
Automation
Automatic
Extra Services
Cut To Length
Certification
ISO 9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
WF67K-500/6000 cnc metal plate bending machine
Characteristics
Such metal plate bending machine has following features:
- Basic machine of digital control bender uses the WF67Y series bender;
- The plate-length positioning device (X) and slipper stroke(y)are automatically controlled by computer;
- Plate-length positioning device uses a general screw rod;
- Control precision of electric automatic positioning device for extruded-plate length is below 0.1mm; Control precision of electric automatic positioning device for dead limit stop is below 0.01mm;
- Positioning occurs in one direction;
- Driving gap of the thread bar is eliminated;
- Limit stop backs off automatically so that the limit stop does not impact the work piece;
- Quick position demonstration.
- The machine tool about the engine bed and behind is equipped with safety feature in the left and right as well as behind, the electric apparatus cabinet is equipped with circuit breaker and around is equipped with the emergency switch to install the system, and have the pedal switch, to guarantee operational safety.
Real Photos:
Kinds of colors for your choice/can be Customized according to user's demand;
Main Technical Data
WF67K-500/6000 cnc metal plate bending machine is:
Specifications |
Unit |
Parameter |
Nominal Pressure |
KN |
5000 |
Bench length |
mm |
6000 |
Pole distance |
mm |
4800 |
Slipper stroke |
mm |
320 |
Throat depth |
mm |
400 |
Max. opening height |
mm |
710 |
Slipper Max. stroke |
mm |
320 |
The number of runs |
times /1 minutes |
2-3 |
Main power |
Kw |
37 |
Oil pump |
|
100SCY14-1B |
Pole thickness |
mm |
100 |
Slipper thickness |
mm |
100 |
Workbench thickness |
mm |
110 |
Weight |
t |
46 |
Dimension(L*W*H) |
mm |
6100x2900x4200 |
Factory Overview
FAQ
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
