Help CenterCatalogue of CW6280e Horizontal Manual Gap Lathe Machine for Sale
Related Products
-
CW6280Ex4000 Universal Metal Horizontal Lathe MachineUS$ 24,000 - 24,100MOQ: 1 Set -
CW6263x6000 Universal Horizontal Lathe With GAPUS$ 30,400 - 30,786MOQ: 1 Set
-
CDL6241x750 Light Duty High Speed Universal Lathe MachineUS$ 5,708 - 5,808MOQ: 1 Set
-
CDS Series Lathe With CE and CQCUS$ 7,055 - 12,230MOQ: 1 Set
-
CW6263x1000 Conventional Lathe PriceUS$ 15,000 - 15,300MOQ: 1 Set
CW6280 gap lathe machine specification
Such horizontal gap lathe machine has following features:
l Standard spindle head: C11, spindle bore Φ100mm,
Optional spindle head: D11,spindle bore Φ130mm;
l Guide rail width:550mm
l Guide rail hardness:HRC50,Depth1.5mm
l Max load weight between 2-centers:1000kg;
With steady rest: up to 2000kg;
l Standard: Left-hand wheel is equipped;
Right-handed wheel shall be informed specially when placing order;
l Equipped with hydraulic clutch and electrical cabinet;
l Slide board boxes with vertical and horizontal rapid shift handle included;
l Special indication is required iftailstock sleeve is with a scale;
Specifications |
Unit |
Parameter |
Max. swing over bed |
mm |
800 |
Max. swing over carriage |
mm |
520 |
Center distance |
mm |
750 1000 1500 2000 3000 4000 5000 6000 |
Width of gap |
mm |
320 |
Swing over gap |
mm |
1000 |
Width of guide way |
mm |
550 |
Spindle bore diameter |
mm |
105 |
spindle nose |
|
C11/D11 |
Spindle speed |
rpm |
(18 speeds) 7.5~1000 |
Longitudinal feed |
mm/r |
(64) 0.1~24.3 |
Cross feed |
mm/r |
(64) 0.05~12.15 |
Rapid traverse speed |
m/min |
3.8 |
Metric thread |
mm |
(39)1~240 |
Inch thread |
TPI |
(26) 14~1 |
Module thread |
mm |
(53) 0.5~120 |
Diametrical pitch thread |
D.P |
(24) 28~1 |
Max. travel of cross slide |
mm |
493 |
Travel of top slide |
mm |
200 |
Main motor power |
kW |
11 |
Rapid traverse motor power |
kW |
1.1 |
Coolant pump motor power |
kW |
0.09 |
Wooden box/Pallet packing |
mm |
|
Gross/Net weight |
kg |
