1400C Refractory Ceramic Fiber Module

1400C Refractory Ceramic Fiber Module thumbnail-1
1400C Refractory Ceramic Fiber Module photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Yao Xing
Model Number:
YXTX-589
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Yao Xing
Model Number YXTX-589
Application heat insulation material
Dimensions 300*300*200mm
Working Temperature 1300℃
Fiber Diameter 3μm
Thermal Conductivity 0.045
Shrinkage (1800℉, 3h) ≤-3%

Specifications

Yao Xing ceramic fiber module with anchor is sold abroad, including North America, East Asia, Africa.


Product Description



 Characteristic:

 Ceramic fiber folded module not only used in furnace, but also brought following benefit with ended custom:

1.Folded blanket will impact tight with each other in differently way without gaps after release from packing.

2.Elastically fiber blanket can withstand mechanical force.

3.The elasticity of fiber blanket could make up distortion of furnace casing and with gaps between modules.

4.Low thermal conductivity can save much energy.

5.Excellent thermal shock resistance capability.

6.Can be betaken immediately as soon as being installed, for there is no need to be dried and maintained.

7. The Anchor system should be far away from the hot surface of the modules and kept in the lower temp.



Technical Index

Classification Temperature

1050

1260

1400

Code

YXTX-189

YXTX-289

YXTX-389

TXTX-489

TXTX-589

Shrinkage on Heating (%)

950°C×24h≤-3

1000°C×24h≤-3

1100°C×24h≤-3

1200°C×24h≤-3

1350°C×24h≤-3

Theoretical Density (kg/m3)

200±10

Shot Content

(φ≥0.25mm)(%)

≤15

Theoretical

Thermal Conductivity

(W/m·k)

0.050-0.060(200°C)

0.095-0.120(400°C)

0.160-0.195(600°C)

 Al2O3 (%)

≥44

≥45

≥45

52-55

38-40

Al2O3+SiO2 (%)

≥96

≥97

≥99

≥99

-

ZrO2 (%)

-

-

-

-

15-17

Al2O3+SiO2+ ZrO2 (%)

-

-

-

-

≥99

Fe2O3 (%)

≤1.2

≤1.0

≤0.2

≤0.2

≤0.2

K2O+Na2O (%)

≤0.5

≤0.5

≤0.2

≤0.2

≤0.2

 Specification (mm)

300×300×200,According to your requirements

Package

Woven Bag/Carton

Quality Control System

ISO9001-2000 ,ISO14001-1996

1400C Refractory Ceramic Fiber Module1400C Refractory Ceramic Fiber Module1400C Refractory Ceramic Fiber Module

1400C Refractory Ceramic Fiber Module1400C Refractory Ceramic Fiber Module




Packaging & Shipping

1400C Refractory Ceramic Fiber Module1400C Refractory Ceramic Fiber Module
