Home > Chemicals > Inorganic Fiber > Ceramic Fiber > Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module

Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module thumbnail-1$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module thumbnail-2$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module thumbnail-3$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module thumbnail-4$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module thumbnail-5$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module thumbnail-6$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module photo-1$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module photo-2$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module photo-3$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module photo-4$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module photo-5$

$Refractory Ceramic Fiber Module High Quality Ceramic Fiber Module Thermal Insulation Ceramic Fiber Module photo-6$

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Feature:

Normal

Contact Supplier Request Quote Chat Now

Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Feature Normal

Product Description

Ceramic Fiber Module

YAO XING modules are made from ceramic fiber blanket stacked with cut edges exposed,

and anchor systems to enable quick, easy and efficient installation in most furnace linings.

These prefabricated modules are designed to meet the thermal insulation

requirements of high temperature furnaces.
Classification Temperature: 1050°C ,1260°C, 1400°C,
Density: 200/220kg/m3

Advantages

1. Excellent thermal and physical stability
2. Low thermal conductivity
3. Low heat storage
4. Excellent corrosion resistance
5. Faster temperature cycling

6. Fast and easy installation

Availabilities

300mm x 300mmx 200~300mm (Thickness)

Custom sizes available upon request
Z-Block modules are available upon request,

Applications

1.Oil heaters

2.Reformer
3.Forge furnaces
4.Process heaters
5.Preheating furnaces

6.Crude oil heaters
7.Fume incinerators
8.Tunnel kilns
9.Cracking Furnaces
10.Shuttle kilns
11.Annealing furnaces

Technical Index:

Classification Temperature	1050	1260		1400
Code	YXTX-189	YXTX-289	YXTX-389	TXTX-489	TXTX-589
Shrinkage on Heating(%)	950°C×24h ≤-3	1000°C×24h ≤-3	1100°C×24h ≤-3	1200°C×24h ≤-3	1350°C×24h ≤-3
Theoretical Density (kg/m3)	200±10
Shot Content (φ≥0.25mm)(%)	≤15
Theoretical Thermal Conductivity (W/m·k)	0.050-0.060(200°C)
	0.095-0.120(400°C)
	0.160-0.195(600°C)
Al2O3 (%)	≥44	≥45	≥45	52-55	38-40
Al2O3+SiO2 (%)	≥96	≥97	≥99	≥99	-
ZrO2 (%)	-	-	-	-	15-17
Al2O3+SiO2+ ZrO2 (%)	-	-	-	-	≥99
Fe2O3 (%)	≤1.2	≤1.0	≤0.2	≤0.2	≤0.2
K2O+Na2O (%)	≤0.5	≤0.5	≤0.2	≤0.2	≤0.2
Specification (mm)	300×300×200,According to your requirements
Package	Woven Bag/Carton
Quality Control System	ISO9001-2000 ,ISO14001-1996
