Ceramic Fiber Board Alumina Silicate Fibre Board

Ceramic Fiber Board Alumina Silicate Fibre Board thumbnail-1
Ceramic Fiber Board Alumina Silicate Fibre Board photo-1
US$ 0.26 - 0.32 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Application:
Liners Of Industrial Furnace
Thickness:
10-150mm
Width:
400/500/600mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Application Liners Of Industrial Furnace
Thickness 10-150mm
Width 400/500/600mm
Length 600/900/1000mm
Grade HP (High Pure)
Chemical Composition Al2O3 SiO2
Working Temperature 1050
Fiber Diameter 3um
Thermal Conductivity 0.075
Shrinkage (1800℉, 3h) <3%
Place of Origin Shandong, China
Model Number YXTX-334
Brand Name Yaoxing

Specifications

Yao Xing ceramic fiber board:
1.Vacuum Forming;
2.Double-sided polished;
3.Environment-Friendly;
4.Easy construction.

Vacuum Formed Boards

YAO XING boards are high performance insulation products manufactured from ceramic fiber (or with alumina fiber) and binders, with YAO Xing’s unique shot removing and vacuum forming process, provide excellent high temperature stability, extra low thermal conductivity, high compressive strength.

YAO XING boards can be easy to saw, drill and die-cut, used as hot-face or back-up thermal insulation in various high temperature applications in furnaces, kilns etc. Additional hardness and strength can be reached with post treatments. Available in variety of compositions, densities, sizes and post treatments combinations, YAO XING board is one of the most versatile products available to the industry today.

Classification Temperature   1050°C,1260°C, 1360°C, 1430°C,1600
Density: 280-650kg/m3

Advantages

 High temperature stability
Low thermal conductivity
 Low heat storage
Non-wetting to molten aluminum

Good flexural and compressive strength
Close tolerance with excellent surface finish
 Easy to cut, drill or saw





Availabilities

 Thickness: 5-100mm
 Dimension: 900 x 600mm, 1000 x 500mm,
                     1200 x 1000mm,600 x 400mm

Applications

 Furnace linings
Kiln furniture
Hot gas duct linings
Refractory backup insulation
Launder insulation
General molten metal contact
Fire protection systems
Glass tank side and wall insulation
 Expansion joint material
Combustion chamber insulation
High temperature gasket and seals







ceramic fiber board alumina silicate fibre board
