Specifications
Ceramic fiber board:1.classification temp:1400Deg.C
2.Type: High Zirconium
3.Specification:900*600*50mm
Description
Zibo Yaoxing is a professional manufacturer of ceramic fiber products for more than 10 years.
Ceramic Fiber Board is made of from high quality refractory fiber and binders,which have a low organic content,through vacuum forming and drying process.
Prduct Characteristic
• Low thermal conductivity
• Low thermal capacity
• High thermal stability
• Excellent resistance to thermal shock, flame and airflow attack
• High compressive strength and resistance to corrosion
• High toughness, easy to cut and install quickly
• Accurate thickness and size
• Shorter heat up and cool down time
• Asbestos free.
Application Range
• Insulating backup to brick & castable
• Furnace hot face lining
• Use in industrial heat process equipment
• High temperature gasket & seals
• Flue & chimney linings in furnace & kilns
• Molten metal trough covers
• Expansion joint Industrial heat shields & thermal barriers
• Industrial combustion chamber construction
• Full thickness refractory lining
• High temperature boiler wall insulation
Name |
CO |
ST |
HP |
Code |
YXTX-134 |
YXTX-234 |
YXTX-334 |
|
Shrinkage on Heating (%) |
950×24h≤-3 |
1000×24h≤-3 |
1100×24h≤-3 |
|
Theoretical Thermal Conductivity W/(m·k) |
0.060-0.085(200°Caverage) 0.092-0.112(400°Caverage) 0.112-0.126(600°Caverage)
|
||
|
Compressive Strength ≥(Mpa) |
0.5 |
||
|
Theoretical Density (kg/m3) |
220-320 |
220-400 |
220-450 |
|
Moisture Content (%) |
≤1 |
||
|
Organic Content (%) |
≤8 |
||
|
Specification (mm) |
1200/1000/900/600×1000/600/400×10/20/30/40/50 According to your requirements |
||
Package |
Plastic Bags inside, Carton outside |
||
Quality Control System |
ISO9001-2000 ISO14001-1996 |
||
