CKE6130/36/40 smaller flat bed cnc lathe machine
- All main components, bed, headstock, saddle, plinth, etc., are high-quality solid castings.
- Low friction Turcite-B coating on mating surfaces between saddle and guideways.
- Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
- Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
- Choice of two model ranges. The CKE-Z series has automatic headstock gear changing, high spindle speed with wide range, and low noise levels of under 80db.
- The CKE-I series, with independent spindle structure, utilizes a frequency converted spindle motor or servomotor to offer stepless high spindle speeds.
- Operator adjustable control panel enables convenient tool setting.
- Fully enclosed guards with interlock offer a waterproof and chip-free environment.
- Horizontal /vertical 4-P automatic tool post is provided as standard, while vertical 4-P indexing tool post, horizontal 6/8-P tool post, quick-change toolpost, etc can also be supplied to suit customers' specific requirements.
- Optional pneumatic or hydraulic chuck and tailstock are available.
- FANUC, SIEMENS, FAGOR, etc control systems can be supplied.
- E-hand wheel function is also available.
- 3 kinds of main motors for your choice: 2-speed main motor; varaible-frequency main motor and Servo main motor;
Item |
CKE6130i |
CKE6136Z |
CKE6140Z |
Max. swing over bed(mm) |
300 |
360 |
400 |
Width of bed (mm) |
205 |
300 |
300 |
Max. length of work piece (mm) |
600 |
750~1000 |
750~1000 |
Max. swing over slide(mm) |
145 |
180 |
200 |
X travel (mm) |
190 |
205 |
225 |
Z travel (mm) |
550 |
620~870 |
620~870 |
Spindle nose |
A2-5 |
A2-6/D6 |
A2-6/D6 |
Chuck size (mm) |
165 |
200 |
200 |
Taper of spindle bore |
M5 |
M6 |
M6 |
Spindle bore (mm) |
40 |
52 |
52 |
Steps of spindle speed |
step less |
2-step actuator |
2-step actuator |
Frequency conversion motor power (kW) |
4.0 |
5.5 |
5.5 |
Rapid traverse X/Z (m/min) |
4/5 |
4/5 |
4/5 |
Vertical 4-position Tool post changing time (s) |
2.1 |
2.4 |
2.4 |
Horizontal 6-position Tool post changing time(s) |
2.8 |
3.0 |
3.0 |
Diameter of tailstock quill (mm) |
42 |
63 |
63 |
Travel of tailstock quill (mm) |
110 |
130 |
130 |
Taper of tailstock quill |
M3 |
M4 |
M4 |
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 7 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
1. 30% down payment, 70% by T/T before shipment;
2. 100% LC at sight(optional and shall be discussed before placing order);
Minimum Order Quantity:
1. 1 Set;
2. ≥2 sets, there will be much discounts.
Warranty:
1. Normally, 12 months for parts as of delivery of the machines;
Shipment:
1. For machine itself, by sea or train(inland countries).
2. For documents, by international express. eg DHL, TNT or EMS.
