Home > Electrical & Electronics > Electric Motor > AC Motor > Air Conditioner Air Purifier

Air Conditioner Air Purifier

Name: Air Conditioner Air Purifier
Brand: YCB, YCB
SKU: 102633363
Availability: InStock

Air Conditioner Air Purifier thumbnail-1

US$ 4 - 15 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Brand Name:

YCB, YCB

Model Number:

YFD

Type:

Asynchronous Motor

Contact Supplier Request Quote Chat Now

Zhejiang Yongchang Electric Corporation

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name YCB, YCB

Model Number YFD

Type Asynchronous Motor

Frequency 50/60Hz

Output Power 25W

Protect Feature Other, IP00

Certification CCC, CE, ROHS, UL, Other, CCC, CE, ROHS, UL, CE CCC

AC Voltage 208-230 / 240 V

Place of Origin Zhejiang, China

Efficiency IE 2

Specifications

Wash-Machine washing motors
Certificate: 3C&CE
Service: we could purchase another parts or product for you !

1,Specification

The motors can be customized according to the customers need with different Voltage,Frequency ,etc.

Code	A	B	C	D	E	F	L1	L2	L3
Size	M6	7	Φ 8	45	8	11.5	28	34.2	68
	M6	7	Φ 8	45	10	10	28	34.2	68
	M6	7	Φ 8	45	12	12	35	35.5	70.5
	M6	7	Φ 8	45	10	10	35	35.5	70.5

2,Performance parameters

The specification of our general products as below:

Model	Voltage(V)	Frequency(Hz)	capacitance(uF)	Insulation class	Rated speed(r/min)	Output power(W)	efficiency(%)	Adjusted form
YFD25-6	220	50/60	2	E	700-1100	25	43	Single Speed
YFD40-6	220	50/60	3	E	700-1100	40	44	Single Speed
YFD25-6	110	50/60	3	E	700-1100	25	41	Single Speed

3,Raw Material

Silicon Steel for Rotor and Stator

Steel for Shaft

Iron or Aluminum Cover

Copper or Aluminum enameled wire

4,Manufacturing process

5,Packing detail

4 pcs one carton with foam

one container (20GP)containing 6000pcs

One pallet 252 pcs for spin motor.

One pallet 216 pcs for wash motor.

One container (20GP)containing 20 pallet

Can be customized according to customer’s requirement packaging.

6,Why choose us

1) Safe and reliable, low noise, good starting, long life, etc.

2) All our products pass the CE/CCC/ROHS/SGS/ISO9001/TUV/BV

2) This motor can be designed and produced according to your request.

3) We will send you some samples for your further inspecting.

4) We have more detailed specifications.If you are interested in, please mail us.

7,Certification,Patent,ISO

All our products passed the CE/CCC/ROHS/SGS/ISO9001:

If you have further questions , please mail us ! We will meet your requirements.

Sales Department

Tel:86-188 5721 1888

Email:admin@

Skype:hzbryant

Web:

Our company was established in 1994,it occupied a land area of 20280 square meters and specialized in micro-motors manufacturing. Owing good service,variety of high quality products and competitive price. We ensure efficient delivery,enjoying a good reputation among our customers.
