cobble stone screening:
The cobble stone screening is a new type of multi-layer, high efficiency round cobble stone screening . The cobble stone screening is with adjustable amplitude, material screen of long line, multi-layer screen separation, clear screening of each specification, high efficiency of screening and it is widely used for product grading in departments of mining area, sandstones, building materials, transportation, energy, chemical industry, etc. (Note: our company can provide cobble stone screening of different specification and various vibration types according to the requirements of the consumers.)
The cobble stone screening is widely used for grading and screening materials in the followingfields: minerals, quarry, building materials, water conservancy and hydropower,transportation, chemical industry, smelting and so on.
cobble stone screening Features and Benefits
The cobble stone screening features long flowing line, many screening specifications, strongviolent vibration force, high screening efficiency, small vibrating noises, firm and durable construction, convenient maintenance and safe operation.Operating PrincipleVibrosieve adjusts the amplitude by tube-shaped violent vibration screen ofeccentric shaft and eccentric blocks. The body moves like a circle, in order tomake the materials screened.
If you are interested in cobble stone screening , please call us or visit the website of the company for relevant prices and detailed technical parameters and specifications etc. Shanghai Shibang Machinery Co., Ltd. will provide quality service to you!
| Model | Layers | Screen Area (m²) | Sieve Pore Size (mm) | Spec. of Screen (mm) | Max. Feed Size (mm) | Capacity (t/h) | Vibrating Frequency (Hz) | Double Amplitude (mm) | Power (Kw) | Weight (Excluding Motor) (t) | Overall Dimension (LxWxH) (mm) |
| 2YA1237 | 2 | 4.44 | 3~50 | 1200x3700 | 200 | 7.5~80 | 800~970 | 8 | 5.5 | 2.34 | 4642x2250x2659 |
| 3YA1237 | 3 | 4.44 | 3~50 | 1200x3700 | 200 | 7.5~80 | 800~970 | 8 | 7.5 | 3.05 | 4898x2250x3133 |
| 2YA1548 | 2 | 7.2 | 5~50 | 1500x4800 | 400 | 50~208 | 970 | 8 | 15 | 5.33 | 5802x2585x3053 |
| 3YA1548 | 3 | 7.2 | 5~50 | 1500x4800 | 400 | 50~250 | 970 | 8 | 15 | 6.07 | 6046x2585x3537 |
| 2YA1848 | 2 | 8.64 | 5~80 | 1800x4800 | 400 | 50~260 | 970 | 8 | 18.5 | 6.65 | 5802x2947x3053 |
| 3YA1848 | 3 | 8.64 | 5~80 | 1800x4800 | 400 | 50~300 | 970 | 8 | 18.5 | 6.93 | 6046x2947x3538 |
| 2YA1860 | 2 | 10.8 | 5~80 | 1800x6000 | 400 | 50~300 | 970 | 8 | 22 | 7.52 | 7011x2947x3471 |
| 3YA1860 | 3 | 10.8 | 5~80 | 1800x6000 | 400 | 50~350 | 970 | 8 | 22 | 7.72 | 7243x2987x3955 |
| 4YA1860 | 4 | 10.8 | 5~80 | 1800x6000 | 400 | 50~350 | 970 | 8 | 22 | 8.70 | 7498x2987x4439 |
| 2YA2160 | 2 | 12.6 | 5~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 | 10.2 | 7076x3402x3666 |
| 3YA2160 | 3 | 12.6 | 5~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 | 10.5 | 7284x3467x4092 |
| 4YA2160 | 4 | 12.6 | 5~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 | 10.8 | 7551x3467x4582 |
| 2YA2460 | 2 | 14.4 | 5~150 | 2400x6000 | 400 | 150~700 | 730 | 6~8 | 37 | 10.4 | 7046x3770x3603 |
| 3YA2460 | 3 | 14.4 | 5~150 | 2400x6000 | 400 | 150~700 | 730 | 6~8 | 37 | 10.8 | 7289x3 |
cobble stone screening Production Line in Operation
SHANGHAI SHIBANG MACHINERY CO., LTD is one high-tech enterprise, which involves R&D, production, sales and service as well. In the past 20 years, we devote to producing mining equipments, sand making machines and industrial grinding mills, offering expressway, rail way and water conservancy projects the solution of making high grade sand and matched equipments.
The head office of SBM is in Shanghai- the international financial centre. Here we have modern production base of 2.3 million square meters, professional R&D institution and technology team, which make us world-class company. Here all SBM machines are designed produced, assembled and texted according to the ISO9001:2008.
Till now, our products are sold to 130 countries, being the popular equipments in global crushing and grinding industry. With the development of our SBM, we would like to help more and more customers start their business in mining and construction industries, offer them the best solution, much more advanced machinery and better service.
1. We are Manufacturer (Not Dealer):
All machineries from SHANGHAI SHIBANG MACHINERY CO., LTD are made by ourselves, with lower price, good quality and assured full after service.
2. Training & Service:
1.We provide you with the prophase plan, process flow design and manufacture equipment according to your special demand.
2.Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3.We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
3. If you are new for this business:
Many thanks for your trust; we can provide you with design scheme for complete production lines, spot inspection and operator training according to your demands and the conditions of applied spot, we can help you choose the right equipments.
4. We’d like to recommend a suitable model for you and send you a best quotation. So please give us some more information about your requirement in your enquiry.
♥ What is the type and size of raw material?
♥ What is your required capacity(t/h)?
