factory price dvb s2 s16 original 1080p ali3606c satellite receiver
products description
*Receive Digital High Definition (HD) and Standard Definition (SD) Satellite Signal
*Supports DVB-S, DVB-S2, MPEG-2 & MPEG-4
*Digital Video Recorder through USB (external flash or hard drive can support but not included)
*Worldwide compatible
*Hardware Blind Search DVB-S and DVB-S2
*Multilingual support on screen menu (OSD): English, French, German, Italian, Russian, Spanish, Portuguese, Turkish, Polish, Arabic, Persian, and so on
*400 MHz MIPS Processor - ALi OS
*Fully compliant MPEG-4 H.264/AVC Main Profile Level 3 & High Profile Level 4.1;
*Fully compliant MPEG-2 MP@HL & MP@ML;
*Fully compliant MPEG-1 Layer I & II & III,
* Digital Audio (AC3)
*SCPC & MCPC receivable from C/Ku band satellites
*Multiple LNB-Switching controls (supports DiSEqC1.0/1.1/unicable)
*Motor Support: DiSEqC 1.2/1.3 (USALS - GoTo X)
*HD 1.3 output
*PVR (store on USB external disk)
*Multimedia files playback (by USB);
*7 Days Electronic Program Guide (EPG)
*Teletext and subtitle out through OSD
*Multi-lingual DVB subtitle and teletext
*Automatic and Manual Channel Scan, Automatic Service Scan
*NIT search, Hardware BLIND SEARCH
*Fast channel switching < 1 second
*OSD in many languages and skin-support
*Multilingual support on screen menu (OSD)
*Multiple display modes: 1080i/720p/570p/576i/480p;
*Videotext Decoder
*Analog RCA audio output: stereo (L+R);
*Digital audio output: S/PDIF by coaxial
*S/PDIF Interface for digital bit stream out (AC-3)
*YCbCr Component Video Output
*1 x Scart (RGB, FBAS or S-Video)
*Screen format: Auto, 4:3, and 16:9;
*Upgrade software through USB2.0 port
*Powerful user interface program management function, parent lock
*US or Europe Power supported (please specify when ordering)
*1XCA (Smart card reader) modules of various coding systems (Crytoworks, Nagravision, Viaccess, Irdeto, Conax,BISS) for the reception of pay TV
*10/100Mbit Ethernet Interface (Support CCCAM, NEWCAM,MGCAM.)
*1x CI common interface
Specification:
DVB-S2
Input Frequency: 950~2150MHz
Loop Out Frequency: 950~2150MHz
Input Level:-65~-25dBm
Input Impedance: 75
LNB Power: Auto/14v/18v/OFF, IMAX = 500mA
Video decoder
Video Compression MPEG-2 and MPEG-1 compatible, H.246
Video Formats 4:3 / 16:9
Letterbox for 4:3 TV-Devices
Audio decoder
Audio Compression MPEG-1 & MPEG-2 Layer I and II, MP3
Audio Mode Dual (main/sub), Stereo
Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz
Output digital
Output Level 0,5 Vss on 75 Ohm
Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
S/PDIF-Output optical, Toslink
Video parameter
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm
Teletext filter in conformity with ETS 300 472 Standard
TV-Scart
Output: FBAS, RGB, S-Video
Serielle Interface RS 232
Typ RS232 bidirectional
Bit rate 115, 2 kBit/s max.
Plug Connector SUB-D-9
Ethernet
10/100 MBit compatible interface
USB
1 x USB 2.0 Host, PVR
LNB power and polarization per tuner
LNB Current 500mA max.; short-circuit-protected
LNB Voltage vertical < 14V no load, > 11,5V at 400mA
LNB Voltage horizontal < 20V no load, > 17.3V at 400mA
Count of active satellite position
DiSEqC 1.0/1.1/unicable/1.2 SAT POSITION / SAT OPTION
DiSEqC - Rotor Control
External PSU
Input: 110-240V AC / 50-60Hz / 0.6A
Output: 12V = / 3,0A
Physical specification
Ambient Temperature +15∑C ~ +35∑C
Humidity < 80%
Size (W x D x H): 300 mm x 220 mm x 56 mm
Weight: 1, 8 kg without HDD
Power
AC input range: 100-240VAC 50/60Hz
Power Consumption (Standby): Max. 10W (<1W)
DVB-S2 |
Input Frequency:950~2150MHz |
Video decoder |
Video Compression MPEG-2 and MPEG-1 compatible, H.246 |
Audio decoder |
Audio Compression MPEG-1 & MPEG-2 Layer I and II, MP3 |
Output digital |
Output Level 0,5 Vss on 75 Ohm |
Video parameter |
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm |
TV-Scart |
Output: FBAS, RGB, S-Video |
Serielle Interface RS 232 |
Typ RS232 bidirectional |
Ethernet |
10/100 MBit compatible interface |
USB |
1 x USB 2.0 Host ,PVR |
LNB power and polarisation per tuner |
LNB Current 500mA max.; short-circuit-protected |
Count of active satellite position |
DiSEqC 1.0/1.1/unicable/1.2 SAT POSITION / SAT OPTION |
External PSU |
Input:110-240V AC / 50-60Hz / 0,6A |
Physical specification |
Ambient Temperature +15 °C...+35 °C |
Power |
AC input range: 100-240VAC 50/60Hz |
Packing:
Gift box:32.5*31.5*8.5CM
1x User Manual
1X Openbox S9 HD PVR satellite receiver
1X Remote Control
