Help Center400W Metal Laser Cutting Machine
Related Products
Specifications
1.laser cutting edge no burr,no need to polish2.Adopt flight path design
3.Strong laser beam
1.Introduction
The laser cutting puncher is a system equipment of optical, mechanical and electronic integration. It can implement noncontact cutting and punching on metal or nonmetal sheets or pipes. It is suitable for the laser cutting and punching of stainless steel plate, iron plate, silicon chip, ceramic plate, titanium alloy, epoxy, A3 steel, diamond, etc. It is a type of multifunctional process equipment, featuring stable running, high processing quality, high efficiency, simple operation and easy maintenance.
2. Feature
The pulse YAG laser generator uses ceramic reflecting converging cavity imported from the Britain and Nd:YAG double-lamp pump. The maximum output power is 500W. The control system uses industrial PC to control the laser power supply and work bench to realize the automatic control of space coordinates and laser switch. Highly efficient protection and emergency shutdown devices are integrated to ensure safety.
3. Application
Laser cutting and punching: stainless steel plate, iron plate, silicon chip, ceramic plate, titanium alloy, epoxy, A3 steel, diamond, etc ferrous metal and non-ferrous metal (e.g. carbon steel, stainless steel, ceramic)
4. Parameters
Model |
HT-LCY300 |
HT-LCY400 |
Laser type |
ND:YAG |
|
Rated output power |
300W |
400W |
Maximum output power |
400W |
500W |
Laser wavelength |
1064nm |
|
Minum line width |
0.20mm |
|
Cutting depth |
≤2mm |
≤3mm |
Repeating precision |
±0.05mm |
|
Puse frequency |
≤200HZ |
|
Control system |
PC |
|
Integrity power |
12KW |
20KW |
Power supply |
380V/50HZ/100A |
|
Work bench stroke |
200×200 mm to 1200×1200mm |
|
Dimension | ||
Master unit dimension |
1600×1200×1300mm |
|
Cooling system dimension |
1200×300×900mm |
|
5.Sample picture
6.Repair service:
I. We can provide the main component for each marking machine, because we do not have the maintenance department at overseas . You can send back the problem spare parts to maintenance or replacement the new spare parts for your marker.
II. We depend on our domestic reputation and customer satisfaction to succeed. Therefore, your feedback is extremely important to us.
III. If you have any particular suggestions or questions on our products, please feel free to contact us. We will be very grateful and reply your email or fax within 24 hours.
7.Warranty Services:
One year warranty period (man-made damage is negotiable).
Lifelong maintenance and spare parts supply.
Free design of fixtures as customers required.
Free training for operation staffs.
Free marking samples of customer provided.
