2015 New Style Howo Concrete Mixer Truck 8 m3 6*4 Euro 2 With Free Parts
US$ 40,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
yuanyi
Payment & Shipping
Payment Methods:
Port of Shipment:
china main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 New Condition Concrete Mixer Truck 8 m3 6*4 Euro 2 With Free PartsUS$ 40,000 - 50,000MOQ: 1 Set -
Lowest Price !!! China Concrete Mixer Truck 12m3 for SaleUS$ 56,000 - 57,000MOQ: 1 Set
-
Lowest Price !!! 2015 NEW STYLE Euro 2 6*4 Truck Mounted Crane With Free PartsNegotiableMOQ: 1 Set
-
Manufacturer Sale Truck Mounted CraneNegotiableMOQ: 1 Set
-
2015 Howo Truck Mounted Crane Made by ManufacturerNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
yuanyi
Model Number
JHL5251GJB
Weight
25000
Dimension(L*W*H)
8965*2496*3980
Certification
3c
After-sales Service Provided
Engineers available to service machinery overseas
2015 new style howo concrete mixer truck 8 m3 6*4 Euro 2 with free parts
The mixer series of products produced by our produces adopt Germany's proprietary technology. Products material requirements, the production process, acceptance criteria, adopt the technology provided by the German standards.
This products use the imported motor and hydraulic pump. Dynamic force output by the second class chassis full power take -off through the shaft power to the hydraulic pump, hydraulic pump produces hydraulic energy through tubing to the hydraulic motor, hydraulic motor to convert hydraulic energy into kinetic energy and through reducer reduce and increase twist to the mixing tank, by adjusting the (double-acting variable) servo controller of hydraulic pump Angle so as to realize the drum and reversing and speed in order to realize the concrete charging, stir, discharging operation.
Product Description
| Mixer tank effective volume,m3 | 8 | |||||
| Kerb weight(vehicle/chassis),kg | 13360 | |||||
| Gross mass(vehicle/chassis),kg | 25000 | |||||
| Rated load,kg | 12070/16200 | |||||
| External dimensions(length×weight×height)mm | 8965*2496*3980 | |||||
| Tank paramenter | Reduction | Italy brand PMP reduction | ||||
| Hydraulic pump | Germany brand SPV hydraulic pump | |||||
| Motor | Germany brand SPV motor | |||||
| Speed of mixing bareel(r/min) | 0-16 | |||||
| Mixing obliquity(°) | 10 | |||||
| Capacity of water tank(L) | 400 | |||||
| Residual rate of discharge(%) | <0.5 | |||||
| Hopper maximum size(mm) | 980 | |||||
| wheelbase,mm | 3625+1350 | |||||
| Front/rear overhang(vehicle/chassis),mm | 1500/1390 | |||||
| Wheel track(front/rear),mm | 2022/1830 | |||||
| Minimum ground clearance,mm | 314 | |||||
| Approach/departure angle(vehicle/chassis) | 16(24/33) | |||||
| Maximum speed,km/h | 79 | |||||
| Maximum climbing ability,% | 20 | |||||
| Minimum turning diameter,m | 15 | |||||
| Typical vehicle model | ZZ1257N3647W/N7WA | |||||
| Cab | Model | HW76 | ||||
| Type | Medium length cab ,single berth,up/down and front/back adjustable steering wheel,and safety belt with double locking mechanism,exterior sun visor | |||||
| Engine(optional) | Model | WD615.87 290hp | ||||
| Rated power,kw/rpm | 213/2200 | |||||
| Maximum torque,Nm/rpm | 1160/1100-1600 | |||||
| Displacement,L | 9.726 | |||||
| Type | Inline 6 cylinder,2 valves,supercharged intercooling,rear supercharger | |||||
| Clutch | 430Bdiaphragm spring clutch.Hydraulic control air power assisted.Standard 430A type for WD615.49 engine,Standard 430Btype for 615.69 engine,Standard 430C type for WD615.87 engine. | |||||
| Transmission | SINOTRUK HW series 10 speed transmission,main and auxiliary transmission struct,main transmission with double countershaft,auxiliary transmission with planetary reducer.Standard HW15710 type for WD615.87 engine,standard HW19710 type for WD615.69and WD615.47 engine. | |||||
| Front axle | HF9 drum-type,rated load of 9T | |||||
| Drive axle | HC16 double reduction(central reduction+wheel reduction),speed ratio:5.73,4.8 | |||||
| Suspension | Front and rear leaf spring suspension,front suspension with shock absorber and transverse stabilizer,rear suspension is disconnected type with transverse stabilizer | |||||
| Steering system | ZF8098 steering gear,ZF steering oil pump,system pressure of 18Mpa | |||||
| Brake system | Service brake:dual-circuit pneumatic brake;parking brake:energy storage spring air cutoff brake;auxiliary brake:engine exhaust brake.Standard engine EVB,and with ABS option automatic slack adjuster | |||||
| Electrical system | Voltage:24V;generator:2240W;Starter:24V,7.5kw;battery:12V/165AH,2pieces | |||||
| Tyre | /12.00-24 12.00R20;optional 12.00R24/12.00-24 | |||||
| Tank volume,L | 300 | |||||
