Rotating Unions and Rotary Joints (also known as rotary swivels, rotary couplings) are precision mechanical devices used to transfer fluid from a stationary source, such as a supply pipe, into a rotating piece of machinery. Rotating Unions and Rotary Joints are used in numerous manufacturing processes to cool, heat, or transfer fluid (pneumatic or hydraulic) power.
Rotary Joints and Rotary Unions allow the feed through of water, glycol, air, hydraulic, coolant, MQL, hot oil, steam, vacuum and a variety of other media. Rotary Joints and Rotary Unions that can be configured for installation at the end of a shaft or around-the-shaft.
Deublin Rotating Union 1 1/2 QC C15D-004-02-3A
- Duoflow design
- Self-supported rotating union
- Convex seal ring better suited to handle mechanical and thermal shock
- External mechanism to adjust siphon pipe through end cap
- Nickel-plated front and rear end cap
- Nickel-plated ductile iron housing
- Stainless steel spring
- Heavy duty steel rotor design
-
Dual bearings for extended service life
- Standard Seal and bearings: Special Carbon Graphite
| Elbow Hose Thread Size O | 3/4" | |
|---|---|---|
| Hose Connection | NPT | |
| Housing Connection | Radial | |
| Housing Hose Thread Size B | 1 1/2" | |
| Media | Steam | |
| Passages | Two Passages | |
| Rotor Threaded | Flanged | |
| Seal Combination | Standard Seals | |
| Union Size | 1 1/2" |
| B Port | 1 1/2" | |
|---|---|---|
| C | 137 MM | |
| D | 340 MM | |
| E | 88 MM | |
| F | 13 MM | |
| F1 Max | 47 MM | |
| F1 Min | 47 MM | |
| F2 Max | 45 MM | |
| F2 Min | 45 MM | |
| F3 | 23 MM | |
| G | 24 MM | |
| J | 214 MM | |
| L | 67 MM | |
| M | 89 MM | |
| N | 73 MM | |
| O Port | 3/4" | |
| P Thread | 1/2"NPT IN | |
| Q | 73 MM | |
| R | 260 MM | |
| Z0 | 17 MM | |
| Z1 | 21 MM |
| Max Speed | 400 /MIN | |
|---|---|---|
| Steam Pressure | 17 BAR | |
| Steam Temp | 204 C |
