Help CenterCurtis Model 1207B Programmable Controllers 24V for Walkie Fork/pallet Trucks, Mini Personnel Carriers Series Motor Controller
Related Products
-
Curtis Model 1221M Programmable Controllers 48V/72V for Industrial Trucks, Golf and Utility Vehicles Series Motor ControllerUS$ 50 - 90MOQ: 1 Piece -
Curtis Model 1209M Programmable Controllers 36V/48V/72V for Industrial Trucks, Golf and Utility Vehicles Series Motor ControllerUS$ 50 - 90MOQ: 1 Piece
-
Curtis Model 1205M Programmable Controllers 36V/48V/60V for Industrial Trucks, Golf and Utility Vehicles Series Motor ControllerUS$ 50 - 90MOQ: 1 Piece
-
Curtis Model 1204M Programmable Controllers 24V/36V/48V for Industrial Trucks, Golf and Utility Vehicles Series Motor ControllerUS$ 50 - 90MOQ: 1 Piece
-
Curtis PMC Model 1268 Programmable Controllers for Heavy-duty Golf/utility Vehicles SepEx Motor ControllerUS$ 50 - 90MOQ: 1 Piece
Curtis Series Controllers are available in a wide range of models, from simple analog controllers to sophisticated, microprocessor based controllers with CANbus communications and comprehensive diagnostics.
Curtis PMC 1207B series motor speed controllers are the direct replacements for the earlier 1207A models. They feature a microprocessor based logic section combined with a proven MOSFET power section. The 1207B series controllers are efficient, cost effective and easy to install.
The Curtis PMC 1207B controllers are ideally suited for small electric vehicle applications, such as walkie fork/pallet trucks, mini personnel carriers, sweepers, and other small series or compound motor applications.
1207B
| Vehicle Type | Material Handling |
| Application | Traction |
| Max Voltage [VDC] | 24 |
| Armature Current (2 min) [A] | 250 - 300 |
| Plug Braking | Yes |
| Programmable Parameters | Yes |
| Line Contactor Driver | Yes |
| CANbus | No |
| IP Rating | IP 54 |
Unit: mm
Model |
Voltage (V) |
1 Minute Rating (Amps) |
5 Minute Rating (Amps) |
1 Hour Rating (Amps) |
Typ. Voltage Drop @ 100A (Volts) |
Undervoltage Cutback (Volts) |
Ambient Temp. Range (ºC) |
1207B-41XX |
24 |
250 |
150 |
100 |
0.35 |
16 |
-25 to 50 |
1207B-51XX |
24 |
300 |
170 |
110 |
0.35 |
16 |
-25 to 50 |
Company Name: Suzhou Benign Intelligent Equipment Co., Ltd.
Operational Address: 204A, Bldg. A, Founder Tech Park, No. 188, Suhong East Road, Suzhou, Jiangsu, China (Mainland)
Website: https://img13.fr-trading.com
Contact Mr. Benign Chen
Department: Director/CEO/General Manager
Job Title: General Manager
Telephone: 86-0512-62890289
Mobile Phone: 18020285375
Fax: 86-0512-62890289
Zip: 215000
Shipping
EMS, TNT, UPS, FEDEX Courier for small quantity. Ocean transport for large quantity.
Our Services
Warranty: Two year limited warranty from time of delivery.
