Help CenterPallet Trucks, Stackers and Other Similar Industrial Vehicles With Curtis Model 24V 1220-2201 Motor Speed Controller
Related Products
-
Mobility Aids, Scrubbers, Personnel Carriers, Small Walkers With Curtis Models 1225/1235 Advanced DC Motor Speed ControllersUS$ 50 - 90MOQ: 1 Piece -
Curtis Models 1225/1235 Advanced DC Motor Speed Controllers Used by Mobility Aids, Scrubbers, Personnel Carriers, Small WalkersUS$ 50 - 90MOQ: 1 Piece
-
Curtis Model 1220-2201 Motor Speed Controller 24V for Pallet Trucks, Stackers and Other Similar Industrial VehiclesUS$ 50 - 90MOQ: 1 Piece
-
Curtis Model 1212P-2501 Motor Speed Controller for Light-duty Class III Pallet Trucks and Similar Electric Industrial VehiclesUS$ 50 - 90MOQ: 1 Piece
-
Curtis Model 1212 Motor Speed Controller for Battery Powered Vehicles dc Motor Speed ControlUS$ 50 - 90MOQ: 1 Piece
Curtis Permanent Magnet motor controllers provide fully programmable, 4-quadrant speed control of brushed DC permanent magnet motors, allowing programmable acceleration, deceleration, and current limiting.
The Curtis Model 1220 is a brushed DC permanent magnet motor controller for electric power steering, steer-by-wire systems and only works with Curtis VCL enabled AC traction controllers. The steering motor functions as an actuator to change the angle of the wheel(s) thereby changing travel direction. Model 1220 interprets the steering command input and wheel position feedback, driving the steering motor to move the wheel to the desired position.
Intended applications are Class 3 material handling vehicles suchas pallet trucks, stackers and other similar industrial vehicles.
1220
| Vehicle Type | Industrial |
| Voltage | 24 |
| Armature Current (2 min) [A] | 40 |
| Integral Line Contactor | Yes |
| MultiMode® | No |
| EM Brake Driver | No |
| BDI Output | Yes |
| Seat Lift Function | No |
| Push-too-fast Function | No |
| UL Approved | No |
| TÜV/FDA Approved | No |
| CANbus | No |
| I/O Mapping | No |
Unit: mm
Model |
Nominal Voltage (V) |
Max Boost Current, > 10 Sec (A) |
2 Min Current Rating (A) |
60 Min Current Rating (A) |
1220-2201 |
24 |
50 |
40 |
20 |
Company Name: Suzhou Benign Intelligent Equipment Co., Ltd.
Operational Address: 204A, Bldg. A, Founder Tech Park, No. 188, Suhong East Road, Suzhou, Jiangsu, China (Mainland)
Website: https://img13.fr-trading.com
Contact Mr. Benign Chen
Department: Director/CEO/General Manager
Job Title: General Manager
Telephone: 86-0512-62890289
Mobile Phone: 18020285375
Fax: 86-0512-62890289
Zip: 215000
Shipping
EMS, TNT, UPS, FEDEX Courier for small quantity. Ocean transport for large quantity.
Our Services
Warranty: Two year limited warranty from time of delivery.
