128x64 STN Graphical LCM With Ks0108 Controller and LED Backlight Quality Choice

128x64 STN Graphical LCM With Ks0108 Controller and LED Backlight Quality Choice thumbnail-1
128x64 STN Graphical LCM With Ks0108 Controller and LED Backlight Quality Choice photo-1
US$ 6.5 - 7.5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Caijing
Model Number:
CM12864-2SLDAA-5
Contact Supplier Request Quote Chat Now
Shenzhen AOSZX Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Caijing
Model Number CM12864-2SLDAA-5
Type COB

128x64 STN graphical LCM with ks0108 controller and LED backlight

Product Description

Model No.: CM12864-2
DOT matrix: 128x64 dots
Module dimensions: 93*70*14mm
Viewing display area: 70.7x38.8
Active area: 66.52x33.24mm
Dot size: 0.48*0.48mm
Dot pitch: 0.04*0.04mm
Weight: 83g

 128x64 STN graphical LCM with ks0108 controller and LED backlight

Certifications

 Our factory pass ISO9001 and all products can pass CE,ROHS,SGS.



128x64 STN graphical LCM with ks0108 controller and LED backlight128x64 STN graphical LCM with ks0108 controller and LED backlight128x64 STN graphical LCM with ks0108 controller and LED backlight128x64 STN graphical LCM with ks0108 controller and LED backlight





Company Advantages



14 year's design,manufacture and sales experience
300+ models available,custom orders welcome
exporting to 100+ countries
Free 1-year maintance

Free samples are available for some styles



Related Products

 About graphical lcd module ,we have 120x32 dots matrix lcd module ,122x32 graphical lcd module,128x32 stn lcd display module ,128x64 monochrome lcd module,128x128 lcd display module,160x128 dots matrix lcd display,160x160 stn lcd,

192x64 graphical lcd display module,240x64 lcd,240x128,240x160 and 320x240 lcd module display .

Display Content  Product No. Outline size(mm) V.A(mm) Dot size(mm) Controller Supply Voltage Interface
192x64 CM19264-8 100×60×13 84×31 0.36×0.36 KS0108 5V/3V parallel
240x64 CM24064-1 180×65×13.8 132×39 0.49×0.49 T6963C 5V/3V serial/parallel
240x64 CM24064-2 180×65×13.8 132×39 0.49×0.49 RA8835 5V/3V serial/parallel
240x64 CM24064-8 180×65×13.8 132×39 0.49×0.49 T6963C 5V/3V serial/parallel
240x64 CM24064-10 146×62.5×13 123×42.5 0.45×0.57 T6963C 5V/3V serial/parallel
240x128 CM240128-1 144×104×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x128 CM240128-2 144×104×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x128 CM240128-3 144×104×12 114×64 0.4×0.4 HD61830 5V/3V parallel
240x128 CM240128-4 144×104×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x128 CM240128-5 154×84×12 114×64 0.4×0.4 T6963C 5V serial/parallel
240x128 CM240128-6 144×104×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x128 CM240128-9 144×104×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x128 CM240128-10 144×104×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x128 CM240128-11 144×104×10.8 114×64 0.4×0.4 UC1698U 3V parallel
240x128 CM240128-12 88.5×67×8.5 75.6×41.5 0.285×0.285 UC1698U 3V parallel
240x128 CM240128-12 88.5×67×8.5 75.6×41.5 0.285×0.285 UC1698U 3V parallel
240x128 CM7401 159×101×12 114×64 0.4×0.4 HD61830 5V/3V parallel
240x128 CM7420 159×101×12 114×64 0.4×0.4 T6963C 5V/3V serial/parallel
240x160 CM240160-1 143×96.8×11 104×79.3 0.37×0.4 RA8835 5V/3V serial/parallel
240x160 CM240160-2 91.3×64.5×7.4 69.4×47 0.261×0.261 ST7529 3V parallel
320x240 CM320240-1 143×97.9×11 104×79.3 0.27×0.27 RA8835 5V/3V serial/parallel
320x240 CM320240-2 103×77×12.6 80.4×61 0.225×0.225 RA8835 5V/3V serial/parallel
320x240 CM320240-3 160×109×11 122×92 0.33×0.33 RA8835 5V/3V serial/parallel
320x240 CM320240-4 139×120×12 103×79 0.27×0.27 RA8835 5V/3V serial/parallel
320x240 CM320240-9 103×77×7.9 80.4×61 0.225×0.225 RA8835 5V/3V serial/parallel
320x240 CM320240-12 160×109×11 122×92 0.33×0.33 RA8835 5V/3V serial/parallel
320x240 CM320240-13 139×120×12 103×79 0.27×0.27 RA8835 5V/3V serial/parallel
320x240 CM320240-15 160×109×11 122×92 0.33×0.33 RA8835 5V/3V serial/parallel
320x240 CM320240-20 92.8×71.8×8 79.5×59.5 0.22×0.22 RA8835 5V/3V serial/parallel
320x240 CM320240-23 160×109×11 122×92 0.33×0.33 RA8835 5V/3V serial/parallel
320x240 CM320240-29 139×100×11.4 103×79 0.27×0.27 RA8835 5V/3V serial/parallel
