20x4 Stn Blue White Cob Lcd Display Module With LED Backlight ,splc780d Controller and Pins Connection.

20x4 Stn Blue White Cob Lcd Display Module With LED Backlight ,splc780d Controller and Pins Connection. thumbnail-1
20x4 Stn Blue White Cob Lcd Display Module With LED Backlight ,splc780d Controller and Pins Connection. photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Caijing
Model Number:
CM204-2BLWAA-5
Contact Supplier Request Quote Chat Now
Shenzhen AOSZX Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Caijing
Model Number CM204-2BLWAA-5
Type COB

20x4 character lcd display module with LED backlight ,stn cob blue white

Product Description

Number of characters: 20 characters x 4 lines
Display type: Cob STN/FSTN, blue/gray/yellow-green and negative/positive
Duty: 1/16
Bias: 1/5
Input voltages: 5.0/3.3V DC
Controller: SPLC780D or equation
Connector: zebra
LED backlight colors: white, blue and yellow green
Operating temperatures: 0 to 50/-20 to 70℃
Storage temperatures: -10 to 60/-30 to 80℃
Module dimensions: 118.0 x 43.0 x 12.8mm
VA: 77.0 x 26.3mm
AA: 56.2 x 20.8mm
Character dimensions: 2.95 x 4.75mm
Character pitch: 3.53 x 5.33mm
Dot dimensions: 0.55 x 0.55mm
Dot pitch: 0.05 x 0.05mm

20x4 stn blue white cob lcd display module with LED backlight ,splc780d controller and pins connection.

Certifications

 Our factory pass ISO9001 and all products can pass CE,ROHS,SGS.



20x4 stn blue white cob lcd display module with LED backlight ,splc780d controller and pins connection.20x4 stn blue white cob lcd display module with LED backlight ,splc780d controller and pins connection.20x4 stn blue white cob lcd display module with LED backlight ,splc780d controller and pins connection.20x4 stn blue white cob lcd display module with LED backlight ,splc780d controller and pins connection.





Company Advantages



14 year's design,manufacture and sales experience
300+ models available,custom orders welcome
exporting to 100+ countries
Free 1-year maintance

Free samples are available for some styles



Related Products

 About character lcd module ,we also have 16x1 character lcd module display ,16x2 character LCM,16x4 monochrome lcd display,20x2 lcd ,20x4 lcd display ,40x2 small size lcd module,40x4 lcd display module.



Display Content Model No. Outline Size(mm) V.A(mm) Dots Size Controller Voltage Interface
8x2 CM802-1 40×35×7 28×14 0.5×0.5 SPLC780 5V/3V serial/parallel
8x2 CM802-2 58×32×13.5 38×16 0.56×0.66 SPLC780 5V/3V serial/parallel
8x2 CM802-6 58×32×13.5 38×16 0.56×0.66 SPLC780 5V/3V serial/parallel
12x1 CM121-1 103×35×11 76×25 1×1.4 SPLC780 5V/3V serial/parallel
16x1 CM161-1 80×36×12 64×13.8 0.55×0.7 SPLC780 5V/3V serial/parallel
16x1 CM161-2 122×33×14 99×13 0.92×1.1 SPLC780 5V/3V serial/parallel
16x2 CM162-1 122×44×13.4 99×24 0.92×1.1 SPLC780 5V/3V serial/parallel
16x2 CM162-3 84×44×13.7 62×18 0.55×0.65 SPLC780 5V/3V serial/parallel
16x2 CM162-4 80×36×12 64×13.8 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-10 84×44×12 64×13.8 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-11 80×36×12.5 64.9×15.9 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-12 85×36×11.3 64.9×15.9 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-13 80×36×12.5 64.6×13.8 0.55×0.55 SPLC780 5V/3V serial/parallel
16x2 CM162-15 85×29×11.3 64.9×15.9 0.54×0.62 SPLC780 5V/3V serial/parallel
16x2 CM162-17 85×36×14 62×16 0.55×0.65 SPLC780 5V/3V serial/parallel
16x2 CM162-36 80x36x11.3 64.9x15.9 0.54x0.62 SPLC780 5V/3V serial/parallel
16x4 CM164-1 87×60×12.5 61.5×25 0.55×0.55 SPLC780 5V/3V serial/parallel
16x4 CM164-2 87×55×12.5 61.5×25 0.55×0.55 SPLC780 5V/3V serial/parallel
20x2 CM202-1 116×37×12.5 83×18.5 0.61×0.66 SPLC780 5V/3V serial/parallel
20x2 CM202-2 180×40×14.3 148×23 1.1×1.12 SPLC780 5V/3V serial/parallel
20x2 CM202-3 116×32.5×7.9 87.8×17.5 0.553×0.569 SPLC780 5V serial/parallel
20x2 CM9079 123×25×12.7 85×12.9 0.55×0.65 SPLC780 5V serial/parallel
20x4 CM204-1 98×60×14 76×26 0.55×0.55 SPLC780 5V/3V serial/parallel
20x4 CM204-2 146×62.5×13 123×42.5 0.92×1.1 SPLC780 5V/3V serial/parallel
40x2 CM402-1 182×33×11.5 154×15.8 0.6×0.65 SPLC780 5V serial/parallel
40x4 CM404-1 190×54×13.6 147×29.5 0.5×0.55 SPLC780x2 5V/3V serial/parallel
