SYBWM3-1000 Mold Machine Labour Saving Automatic Robotic Arm

SYBWM3-1000 Mold Machine Labour Saving Automatic Robotic Arm thumbnail-1
SYBWM3-1000 Mold Machine Labour Saving Automatic Robotic Arm photo-1
US$ 3,000 - 8,000 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Vertical Travel(mm):
1000mm
Horizonal Travel(mm):
1500mm
Contact Supplier Request Quote Chat Now
Jinan Qifan International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao / Beijing/ Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Vertical Travel(mm) 1000mm
Horizonal Travel(mm) 1500mm
Application Other, Pick and put
Place of Origin Shandong, China
Brand Name SHENYU
Model Number SYBWM3-1000
Power(W) 2500
Certification CE,SGS
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

SYBWM3-1000 labour saving automatic robotic arm:



Features:

 1)Traverse is mounted steel structure,high quality linear rail,driven by AC servo motor,high quality synchronous belt to move the axis at high speed and strength with precise positioning;

2)Single beam structre on crosswise,high quality aluminum alloy material and linear rail on main body.Driven by AC servo motor,high quality gear wheel and rack to move the axis at high speed and strength,light weight,low noise anf with precise positioning;
3)The single axis servo sidling fulfills multi-point parking.The servomotor realizes crosswise moving ang position adjustment,facilitating the adjustment ang making the operations easy.Under PLC control,the robot features strong interference resistance and modularized design ang stores more than 20 modes.It is simple and easy to understand the manual bo`s interface.



Specifications:

Model Unit SYBWM3-1000 SYBWM3-1200
Type   Telescppic type
Moulding machine size ton 50-180 450-650
Vertical stroke mm 1000. 1200
Traverse stroke mm 900 1050
Traverse stroke mm 1500 1600
Side angle pose ° 90
Max load(Includes gripper) Kg 5 5
Minimun take time Sec 4 4
Dry cycle time(withou gripper) Sec 14.5 14.5
Drive mode   Rampant, crosswise, arms up and down - a servo motor; Posture - Pressure
Working air pressure Kgf/cm² 6
Air consumption NL/cycle 20 22
Power consumption KW 2.5 2.5
Power   AC200±10%(50/60HZ)



    Machine size can be customized.





Machine warranty and after-sale service:



1. Machine warranty is 12 months, broken parts free change during the time.



2. 24 hours technical support by email or calling.



3. Friendly English user manual in video and book.









Our factory:

SYBWM3-1000 mold machine labour saving automatic robotic arm

SYBWM3-1000 mold machine labour saving automatic robotic arm

SYBWM3-1000 mold machine labour saving automatic robotic arm



SYBWM3-1000 mold machine labour saving automatic robotic arm

Robot arm has been widely applied to household appliances, computer and peripherals products, photoelectric, cosmetic, automobile, clocks and watches, precision gear, PET bottle embryo, beach chair, audio-visual music, light guide, communication electronic, mobile phones, medical supplies, medicine packaging, food packaging, etc



SYBWM3-1000 mold machine labour saving automatic robotic arm



To know more information about our machine, please contact us directly:

SYBWM3-1000 mold machine labour saving automatic robotic arm
