2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp

2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp thumbnail-1
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp thumbnail-2
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp thumbnail-3
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp thumbnail-4
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp photo-1
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp photo-2
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp photo-3
2016 Newest Beier20W Solar Powered Led Night PV Lights With Bridgelux Chip for Garden, Park Street Lamp photo-4
US$ 400 - 600 MOQ: 10 Sets
Key Specifications
Get Latest Price
LED Light Source:
22W
Input Voltage(V):
DC12V, DC12V/24V
Lamp Power(W):
22
Contact Supplier Request Quote Chat Now
Jiangsu Beier Lighting Electrical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 22W
Input Voltage(V) DC12V, DC12V/24V
Lamp Power(W) 22
Lamp Luminous Flux(lm) 2160lm
Lamp Luminous Efficiency(lm/w) 120
Color Temperature(CCT) Other, Warm White, Pure White
Working Temperature(℃) -30, 60,
Working Lifetime(Hour) 50000, 50000
Lamp Body Material Aluminum Alloy
IP Rating IP65
Certification CCC, CE, CQC, CCC, CE, CQC
Place of Origin Jiangsu, China
Brand Name Beier
Model Number XJD-20

2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp

Advantages

2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp

Beier Advantage:

  • 23 years solar designing and exporting experience

  • Successfully appiled in more than 50 countries

  • 15 working days delivery time

  • IS09001, CE, RoHS, IEC, FCC, SONCAP, SASO, CCPIT, CCC

  • OEM/ODM avaliable

  • Skilled manufacturer, quality control and technical team

Product Description

High quality maintenance for outdoor 20W solar led street light

LED Lamp Power 20W
Lamp Body Die-casting Aluminum
LED Chip Brand Bridgelux
Luminous Flux (LM) 2160
Lamp Luminous Efficiency(lm/w) 120
IP rate IP65
Reflector Stainless Steel SS304
Cover Glass Toughened Glass
Lifespan 50000 Hrs
Solar Panel Power 60W*1PC
Material Mono Crystalline Silicon
Lifespan 20-25 Yrs
Battery Type 60Ah/12V*1PC
Material Gelled type
Lifespan 5-8 Yrs
Battery Box Material Engineer Steel
Solar Controller Working Voltage 8A/12V
IP Rate IP68
Lifespan 5-10 Yrs
Pole Height 5M
Material Hot-dip Galvanized Steel
Lifespan More Than 20 Yrs
Certificate ISO, CE&EN,RoHS,IEC, Soncap, PVOC&COC, SASO, FCC, CCPIT,CCC
Warranty 3 Yrs



Specification for Component
2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp





LED Description

Lamp body High-pressure die-casting aluminum.Corrosion resistant, IP65 or I68
Reflector High purity aluminum or stainless steel SS304. mirror polish.
Cover glass High strength and high transparent toughened glass.
Arm diameter 48 or 60mm
Lumen 140-150LM/W
Lifespan 50000-100000Hrs









Solar Panel Description

High efficiency and transmission rate, low iron tempered glass

Manufacturing with IEC61215 standard

2 types of solar panel: Mono crystalline silicon & Poly crystalline silicon

2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp
2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp





Solar Battery Description

Low-internal resistance clapboard, low internal resistance, good battery capacity

Self-discharging rate less than 3% every month.

Gassing rate of gelled batteries is only 5% of ordinary sealed batteries.

The lifespan is greater than 1000 times at 25C°





Solar Controller Description

PWM charge control method

Over-voltage protection and under-vloltage protection

Light control, time control, temperature control

Waterproof design

2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp
2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp





Street Pole Description

Welding

Advanced submerge-arc welding and CNC welding equipment.


Galvanization

Hot dip Galvanizing antirust



Painting color

(RAL)Color card or Refer to client’s requirement



Base plate mounted

Base plate is square, octagonal or round in shape with slotted holes for anchor bolt and dimension as per customer’s





Applications

2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp

Company Information

Jiangsu Beier Lighting Electrical Co., Ltd.

Beier Lighting established in 1993 and located in Yangzhou,Jiangsu Province China, is an ISO9001:2000, ISO14001, “CCC” & “CQC” ,AAA,CE, SGS approved manufacturer and exporter of solar street lights, LED streetlight, LED housing, solar battery, solar panel and solar system.



We are good at:

1: Designing, producing solar 10W-120W LED street lights

2: Designing, producing 10W-120W Solar Street Lights for outdoor lighting.

3: Producing solar panel from 40W to 300W

OEM Service for solar lighting and PV panel is available.





 2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp

Packaging & Shipping

Standard Export Carton with foam inside suitable for long-distant ocean shipment and tough handling.

2016 newest Beier20W solar powered led night PV lights with Bridgelux chip for garden, park street lamp

FAQ

[Q:] Why to choose led solar street light?

[A:] LED solar street light has the advantage of energy-saving, environment-friendly, easy to install, maintenance-free, etc.


[Q:] How to choose solar led street light?

[A:] Our technician will design solar street light according to listed factors:

1. The height of pole

2. The working time of solar street light each night you need

3. The proportion of the rainy and cloudy days in installation place of solar street light



[Q:] Can I have the sample of solar street light?

[A:] Suer, you can order the sample for testing the quality of solar street light, but the price of sample is different from the large quantity.



[Q:] Can I have my own logo on the solar street light?

[A:] Yes, OEM service is available for us!
