Specification of Rock Wool Sandwich Panel
Color steel sandwich panel / Rock wool sandwich panel | ||
Type |
color steel sandwich panel (overlap joint) |
|
Dimensions |
Total thickness |
50-200mm |
Width |
950/1150mm (effective width) |
|
Length |
Less than 11.8m |
|
External face |
Material |
PPGI |
Thickness |
0.4-0.6mm |
|
Thickness of the zinc |
80g/m2 |
|
Corrosion protection |
Galvanized |
|
Coating |
Polyester |
|
Thickness of coating |
20 micron |
|
Color |
According to the RAL |
|
Pattern |
Nearly plain |
|
Insulation |
Optional foam Material |
Rock wool |
Thickness |
50-200mm |
|
Density |
100kg/m3 |
|
Thermal conductivity |
0.02~0.03w/mk |
|
Internal face |
Material |
PPGI |
Steel thickness |
0.3-0.8mm |
|
Color |
As your request | |
Corrosion protection |
Galvanized |
|
Coating |
Polyester |
|
Thickness of coating |
7micron |
|
Pattern |
Plain |
|
Advantage:
1.Light in weight: easy to install(donnot need crane), save more construction period and low the cost.
2. Excelent Sound Insulation, heat insulation, waterproof and damp resistant with it's good appearance.
3. Large load: Used as supporting structure and defense device for it's characteristic of high intension rigidity.
4. Panel length is according to the buyer's request, and the steel color is flexible based on the RAL standard, that makes your building more beautiful.
5. Eco-friendly
Features
1. Light weight: Save cost
2. Easy installation
3. Safety: Fire-proof materials
4. Good sound insulation
5. Meet specials designs due to it is easy to form and cut
Application
Worshop, temporary office/buiding, gymansia, villa, mobile building, guard booth, wall & roof materials for steel building or structure.
Trade Term
1. Delivery time: within 15-45 days after the receipt of L/C or deposit
2. MOQ: 500 square meters
3. Packaging details: standard seaworthy packing
4. Payment: T/T or L/C
z lock sandwich panel available either.
