105W Monocrystalline Solar Panel Module From China Manufacturer

105W Monocrystalline Solar Panel Module From China Manufacturer photo-1
US$ 70 - 72 MOQ: 15 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Beier
Model Number:
XHK-105D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name Beier
Model Number XHK-105D
Material Monocrystalline Silicon
Size 801*1074*35mm
Number of Cells 36pcs
Max. Power 105W

Specifications

Solar Panel:
1.CE CCC CQC ISO9001:2000
2. Withstands high wind-pressure and snow load
3. Easy to install.
4, high-quality

Solar panels from 5W--300W

Features:
1. High conversion efficiency based on leading innovative photovoltaic technologies;
2. High stabillity with guaranteed+/-3%power output tolerance, ensuring return on investment;
3. Beautiful appearance;
4. Sealed with high transparency low iron tempered glass, anti-aging EVA, high insulation TPT, with the anodizing (or plating finish);
5. Withstands high wind-pressure and snow load;
6. Easy to install.

Recommended Applications:
1. On-grid utility systems;
2. On-grid commercial systems;
3. Off-grid ground mounted systems;
4. Our products are widely used in solar lighting, lamps, household electricity, traffic, communication, meteorological, building and photovoltaic power plants and other fields.



1ModelXHK-105D
2Power(Pmax±3%)105W
3Voltage at Pmax(Vmp)35V
4Current at Pmax(Imp)2.86A
5Open-circuit voltage(Voc)43V
6Short-circuit current(Isc)3.16A
7Max system voltage(VDC)1000v
8No.of cells and connections36pcs(4*9)
9Cable length15cm
10Size801*1074*35mm
11Weight10kgs
12Operating temperature-40 - +85
13Glass3.2mm
14EVAEVA
15BacksheetTPT
16FrameAI
17Type of output terminalJunction box
18Life25years
