Specifications
SpecificationsOur Multiple Enclosed conductors have passed CCC, CE, ISO and SGS Certifications.
Specifications
Our Multiple Enclosed conductors have passed CCC, CE, ISO and SGS Certifications.
Detailed Product Description
These systems feature multiple conductors, typically copper strips, in an insulated enclosure. The current
collector tracks are inside the enclosure, with the joining electric cable connected via an opening (slot) in the
bottom of the enclosure. The bottom opening can be sealed with a neoprene sealing strip to keep debris and
fumes out. The current collector is self-guided in these systems and only needs to be towed with a towing arm. Multiple copper conductors in an
enclosure (aluminum or PVC housing) is available in 3 to 16 conductors and amperage capacities from 30 to
240.
Enclosed conductor bar has been used successfully for many years and have been continuously improved and
adapted in line with the latest state-of-the-art products. They are conductor bars in a rigid PVC housing with different copper cross sections for rated
currents of 40-200 A. The current collectors, running in ball bearings, are guided by the housing. The mains power is
transferred by spring-stored carbon brushes.
Type HFP for indoor plants is manufactured in green plastichousings for 4 and 5 poles. At up to 100 A we can
supply the Power rail with plug-in joints. Otherwise, the sections are connected bolted joints.
Application
The ranges of applications of HFP Power Rail Enclosed Conductor bar System
1.Overhead and elongated tracks for cranes.
2.Electric hoists, electric tools, stacking systems.
3.Electric tools
4.Other applications for supplying power to moving power load.
Design features:
Compact arrangement, corrosion resistance and simple assembly are its essential features.
|
Current Collector
The current collectors are made of re-inforced polyester fiberglass,for high strength and light weight. Spring loaded carbon brushes maintain uniform contact. Connecting cables and hinged or flexible towing arms included. Double Current collectors for transfer applications and higher amperage. |
|
Fork Multipole current collect fork is made of aluminum alloy (6063A GB), making it more resistant to oxidation, corrosion resistance, high surface finish |
|
Connect Wire Box
The box is used to connect the power line. |
|
Conductor Bar Sheath Conductor Bar Sheath is mainly used to connect components to prevent oxidation, the rain, another also beautify the appearance of conductor bars. |
|
Hangers: Standard brackets for conductor attachment to crane girders are available. Conductor is with sliding and fix point hangers. Standard distance between suspension appoints for indoor and outdoor installations: 1200mm to 1500mm. |
|
Angle steel bracket
Angle steel bracket in the conductor bar system is to put the system in the plant H to fixed bracket Angle steel bracket is made of aluminum alloy 6063A GB, making it more resistant to oxidation, corrosion resistance, high surface finish |
|
End Cap
The open ends of the conductor bar are closed by end caps to protect conductor bar from oxidation, corrosion resistance, high surface finish |
Shandong Kaiqiang Electric Equipment CO., LTD. is a professional manufacturer that specialized in research
development producting and sales. The feature products are Conductor Bar Systems, and aluminum mould.
Our products are optimally designed according to the advanced technology and equipment introduced from
France.
Our company has passed the certification of ISO9001:2000, reached the international standards of DIN534438,
NFEN60529-92, NFC32-070-91 and VDE0470, and met the certification of JB6391.1-92 and JB6391.2-92.
"Quality is our life, integrity is our impetus", the most precious treasure of the Kaiqiang company, is the ultimate
driving force that keeps us moving on.
1 Q: What is your MOQ?
A, If you have agent in China arrange the delivery shipping for you, there will be no MOQ limited.
B, If you need us to arrange the delivery shipping, the MOQ will be 200 meters bus bar and mixed order can be
accepted.
2 Cooperation Procedure:
A, First send us an inquiry for quote, please be specific on products category, products name, products material,
product ampere, product quantity and required delivery time.
B, Then we will send you our best price with our company information.
C,We are glad to send you samples to let you test our products quality. We have our own Express company, so
we promise give you the bottom price of the Freight.
D, We may contact you for clarification or options during this period, please carefully review our quote, please
don’t hesitate to call or email us if you have any question or need any advice, make necessary revisions.
E, After confirming all the information by you, we will prepare a copy of PI (Proforma Invoice) or Purchase
Agreement; we will attach our Bank information.
F, When received your payment, we will start the production at once; when the good are finished, we will take all
the pictures from difference angle for your reference. Then we will arrange the shipment for you at once. At
last we will send you the Commercial Invoice and Packing List, especial the Original B/L.
