Model No:PT-H5861
Main feature :
·VIA VT8601T+VT686B Chipset
.Onboard VIA 400MHz CPU
·Onboard 32M RAM
·1 x RS232,1 x RS232/422/485
.40pin IDE and 44pin connector IDC(1 CF socket)
.Supports LAN/PC104(Optional)
Specification :
CPU |
Onboard VIA 400MHz |
Chipset |
VIA VT8601T+VT686B |
Memory |
Onboard 32M RAM |
Storage |
1*40pin IDE,1*44pin IDE,1*CF |
Expansion Slots |
PC104(Optional) |
|
Back Panel I/O Port |
1 x VGA |
1 x RJ45 10/100M LAN(Optional) | |
1 x RS232 | |
1 x PS/2 KB&MS | |
|
Internal I/O Port |
1 x RS232/485 header |
2 x USB1.1 header | |
1 x LPT header | |
2 x IDE | |
1 x CF(Optional) | |
Watchdog Timer |
Software programmable |
Bus Standard |
Half-size ISA |
Power supply |
DC5V/12V ATX/AT |
Dimension |
185 x 122mm |
OS |
Linux/DOS/Win98/Win 2K |
Operating Temperature |
0°C ~ 60°C |
Storage Temperature |
-20°C ~ 80°C |
Storage Humidity |
5~90%@40°C(non-condensing) |
Ordering information:
PT-H5861 |
Half-size ISA CPU Card, W/VIA 400MHz/32M Ram/1*VGA/2*COM/1*PS2 KB/MS/LPT/IDE |
product pictures:
More Products:
Shenzhen Pontron Technology Ltd we have dedicated in Industrial panel pc,Industrial LCD monitor,KVM, Industrial BOX pc,workstation,Mini pc in the worldwide market for 10 years. our products has the CE/EMC/FCC/ROHS certificate and the customers are all over the world.especially in USA, Europe, Australia and Asia.
Our dedicated team of engineers, production specialists, and administrative staff provide the best quality products available on the market.
We pride ourselves on our expertise in producing customized products. Through ODM/OEM production, you are assured of designs which will meet your exact specifications. Our innovative ideas in manufacturing which will make your products a leading seller on the market. this results in short period of develpoment time for projects.
In PONTRON, we have a qualified working team which includes senior level mechanical and electronic R&D engineers, OEM product/sales manager, ISO 9001 trained manufacturing personel, and an efficient logistics department. we have an average age of 30 years old, and the average working experience in the industrial computer field is more than 7 years.
PONTRON, is committed in prooviding quality, innovative products and technical support to our customers in a very cost effective manner. we like to grow with our customers.we believe customer satisfaction is the key to our growth and success. we work for your needs and your satisfaction is guaranteed.
Packaging: Duoble package 424mm(L) 348mm(W) 80mm(H) ;570mm(L) 430mm(W) 173mm(H).
Delivery time: Within 1day after order and samples are confirmed.
